Explanation of the structure of the anti-loosening bolt "Motion Tight."
Difficult to loosen and difficult to break! A bolt that enhances work efficiency and promotes lightweight and energy-saving. An explanation of the changes in the threads before and after binding!
The "Motion Tight" handled by Art Screw is a revolutionary bolt that eliminates the two major complaints in screw fastening: "loosening and breakage of screws." ■ Explanation of the changes in the screw threads before and after fastening! ■ For more details, please refer to the technical documentation.
basic information
【Patent Numbers】 ■Patent No. 4806103 ■Patent No. 4878407 【Evaluation Tests】 ■NAS Vibration Test → Passed a total of 30,000 rotations of vibration testing in 17 minutes ■Yunker Vibration Test → Comparison data with standard products available on the official website ■Fatigue Test: JISB1081 → Approximately 20% improvement ■Load Distribution Ratio (%) Standard Bolt: Motion Tight → Thread No. 1 32.9： 26.4 → Thread No. 2 19.7： 19.6 → Thread No. 3 14.1： 15.6 → Thread No. 4 11.5： 13.4 → Thread No. 5 10.4： 12.2 → Thread No. 6 11.4： 12.8 → Total 100.0： 100.0 *Motion Tight has a more averaged load distribution ratio compared to standard products, resulting in higher fatigue strength and reduced likelihood of breakage. ■Torque and Axial Force Test → Variability of axial force is about half that of standard products *For more details, please refer to the catalog. Feel free to contact us with any inquiries.
Price information
Please contact us.
Delivery Time
Applications/Examples of results
For more details, please contact us or download the catalog.
