■Color Display - 7-inch color display - Supports multiple languages: Japanese, English, and Chinese - Displays load, pressure, displacement, and time - Configurable test items Test speed, direction of load, automatic return, measurement stop at sample breakage - Analysis items Numerous including maximum load, interval load, load at break point, etc. - Setting of test stop conditions - Configuration of test stop conditions for sensor overload, maximum displacement, time overrun, etc. - Storage of up to 50 test data (also possible to save to USB) - Function to return to factory settings - Calibration mode for standalone device - Unit system switching (SI units and US units)

■Long Extension Meter (QC-551) The Long Extension Meter is suitable for testing materials with an elongation rate of 20% or more, such as rubber, resin, and fibers. It accommodates dumbbell-shaped samples and, when connected to a Cometech testing machine, measures the elongation of the sample in real-time during the test.

■Short Extension Gauge (QC-557) The short extension gauge is suitable for tests with a strain rate of less than 100%, such as metals and hard resins. It captures the displacement speed in real-time during testing. If the test specimen is larger than the measuring gauge, custom manufacturing is available.

■Software Features - Maximum sampling rate of 400Hz - Control of the device via PC and precise position adjustment using up and down buttons - Support for multiple languages including Japanese, Chinese, English, Korean, Spanish, Portuguese, Polish, and more - Bidirectional communication with PC via TCP/IP - Simultaneous display of multiple test data - Unit switching for display (SI units, US units) - Flexible analysis with data list display - Definition of arbitrary calculation formulas - Display of test data in graphs and tables - Data processing functions: Importing, saving, and statistical comparison of data - Custom selection of parameters for graph X-Y axes, including marks on curves, intervals between marks, slope analysis, etc. - Support for various tests including tension, compression, bending, peeling, springs, and many more - Customizable conditions for stopping the device due to over-travel, overload, and over-time for equipment protection - Support for diverse testing patterns, including repeated tests, creep, stress relaxation (tension/compression), temporary suspension of tests, slip, and tests combining up to 10 stages - Simplified input of sample information through modular sample settings, among others

■Related Grip Three-Point Bending Test Stand Model: GR-C040

■Related Grip Compression Plate Model: GR-G02C
