Improving CAD quality and reducing work hours with automatic healing! [Case study link available]
Data conversion and modification software to assist in data exchange with business partners.
When exchanging CAD data with business partners, it is important to pay attention to the differences in the types and versions of CAD being used. If you do not have the CAD that corresponds to the format of the data received from your partner, you will not be able to open the data as is. Furthermore, even if the format is compatible, inconsistencies may occur, such as surfaces being divided into finer segments when loaded. In such cases, it is necessary to use translator software to convert the data into a readable format or to correct (heal) inconsistencies within the CAD software. spGate is a powerful software that supports data conversion and correction between CAD software. It supports a wide range of formats as standard, so there is no need to purchase expensive additional options to accommodate multiple business partners. Additionally, enhanced healing features improve conversion quality and significantly reduce correction work. We have introduced examples of cases where spGate was implemented to solve data transfer challenges on the following page. Please take a look.
basic information
"spGate" is an all-in-one product developed as an evolved form of a data translator to connect the four main processes of "design, analysis, processing, and inspection" in the manufacturing industry. It enables smooth data exchange between these intricately intertwined processes. Additionally, it supports a wide range of file formats, eliminating the need to purchase expensive options to accommodate the data formats of new business partners. 【Features】 ■ Defect detection according to PDQ guidelines ■ Easier defect correction functionality than CAD systems ■ Reduced analysis time and confidentiality protection through simplification ■ Instantly reduces a 50,000 surface CAD model to 1,000 surfaces ■ Simulates the occurrence of wrinkles
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
catalog（1）
Download All Catalogs
Recommended products
Distributors
Since our establishment in 1984, we have consistently faced the diverse challenges encountered in the manufacturing industry. By combining our customers' extensive know-how with our strength in three-dimensional shape processing technology, we provide solutions that are truly beneficial to manufacturing sites. The pillars of our business are "contract development," which leverages our flexible responsiveness, and "packaged products," which reflect the needs of the field. In both areas, we aim to carefully understand our customers' challenges and utilize our analytical skills from a field perspective along with our solid technical capabilities to deliver valuable products and services.
