Raksun for Manufacturing: Streamlining Dimension Creation for Parts Drawings
Dimension layout as intended by the designer! Achieving a reduction in man-hours for component drawings.
In the manufacturing industry, 2D drawings remain an important source of information for parts management. Accurate dimension information is essential as part of the bill of materials and manufacturing instructions, and the way dimensions are recorded is a crucial factor that affects the quality of the drawings. Raksun is software that analyzes the shape information of 2D drawings and assists in the arrangement of dimensions in line with the designer's intent. By setting rules in advance, such as reference planes and dimension directions, and simply selecting the target with a rectangular selection, dimensions based on those rules are automatically generated. It achieves a "visually appealing arrangement" that was difficult to accomplish with the automatic functions of general-purpose CAD, reducing the burden of manual work. [Usage Scenarios] - Dimensioning parts drawings with complex shapes or numerous holes - Efficiently adding dimensions to 2D drawings - Systematizing the know-how of experienced designers to support younger designers in drafting [Effects of Implementation] - Significantly reduces the effort required for dimension input. - Reduces human error and minimizes variations among different designers. - Prevents discrepancies in interpretation in later processes through drawing based on common rules. "Raksun" allows for flexible customization tailored to the specific design environment of each customer. By incorporating unique dimension creation rules established by the company into the system, a more practical environment can be built. Please feel free to consult with us.
basic information
【Features】 - Automatically arranges necessary dimensions such as outer dimensions and hole spacing simply by selecting a shape and pressing a button. - Supports dimension arrangement in line with the designer's intent. - Dramatically reduces manual labor. - Compatible with AutoCAD 2025 and 2026. - Compatible with AutoCAD Architecture, Mechanical, MEP 2025 and 2026. 【Our Strengths】 Since our establishment in 1984, we have consistently faced the diverse challenges encountered in the manufacturing industry. By merging our customers' extensive know-how with our expertise in three-dimensional shape processing technology, we provide solutions that are truly beneficial to the manufacturing field.
Price range
Delivery Time
Applications/Examples of results
Automatically displays dimensions by specifying the presence or absence of dimension output and the display position.
Related Videos
catalog（1）
Download All Catalogs
Recommended products
Distributors
Since our establishment in 1984, we have consistently faced the diverse challenges encountered in the manufacturing industry. By combining our customers' extensive know-how with our strength in three-dimensional shape processing technology, we provide solutions that are truly beneficial to manufacturing sites. The pillars of our business are "contract development," which leverages our flexible responsiveness, and "packaged products," which reflect the needs of the field. In both areas, we aim to carefully understand our customers' challenges and utilize our analytical skills from a field perspective along with our solid technical capabilities to deliver valuable products and services.
