In-wheel motor for AGV #In-wheel motor
Half the price of domestic equivalents! This is a next-generation in-wheel motor that reduces the cost of AGV development.
The in-wheel motor for AGVs and AMRs provided by Crew Co., Ltd. is an in-wheel motor that solves the cost challenges of hardware procurement. It offers an overwhelming low price of less than half that of domestic equivalents and has a delivery speed system that can deliver standard in-wheel motors within one month of ordering. It adopts a direct drive structure without gearboxes or belts, achieving noise reduction by eliminating backlash and maintenance-free operation by having zero wear parts. In addition to a wide range of sizes from 4.5 inches to 16 inches, you can choose in-wheel motors suitable for various applications, including polyurethane for indoor use, rubber for outdoor use, and mecanum for omnidirectional movement. It is the next-generation in-wheel motor that maximizes the robot's payload and accelerates development.
basic information
【In-Wheel Motor Basic Specifications】 - Drive Voltage: 24V / 48V battery powered - Expected Total Weight: 100kg to 300kg (when using two units) - Size Range: 4.5 inches to 16 inches - Tire Types: Urethane tires, rubber tires, mecanum wheels - Shaft Type: Single shaft (single axis), double shaft (dual axis) - Encoder Types: 1024 / 4096 - Protection Rating (Dust and Water Resistance): IP54 / IP65 - Number of Poles: 10 to 20 Pair Pole - Operating Temperature: -20 to +40℃ - Optional Features: Integration of non-powered operation (NC) electromagnetic brake, synchronous control via dual AC servo drivers - Operating Constraints: Thermistor temperature below 80℃ (intermittent use assumed)
Price information
We have achieved an overwhelming low price of less than half compared to equivalent in-wheel motors from domestic manufacturers. By significantly reducing the initial introduction costs of in-wheel motors, it becomes possible to dramatically increase the number of trials in robotics development and R&D. The price may vary depending on the quantity during mass production and the custom specifications of tire materials and shaft shapes (ODM), so please feel free to request a quote along with the specifications for the in-wheel motor.
Price range
P3
Delivery Time
P4
Model number/Brand name
Crew Corporation In-Wheel Motor HSM Series
Applications/Examples of results
**Main Applications and Implementation Results of In-Wheel Motors** Solutions for Addressing Labor Shortages Our in-wheel motors are used as the drive system for AGVs/AMRs for parts transportation within factories, as well as for smart service robots that autonomously navigate hotels and libraries. Attractions and Entertainment In-wheel motors are actively used to bring creative ideas to life, such as next-generation mobility in amusement parks and small electric machines that children can intuitively ride and play with. Latest Technology Verification and Testing Platforms In-wheel motors are implemented as "testing platforms" for building AI algorithms, testing autonomous driving software, and verifying the operation of various sensors such as LiDAR.
Related Videos
catalog（3）
Download All Catalogs
Distributors
CLUW Inc. specializes in low-voltage battery-driven motors and control drivers, offering a comprehensive lineup from compact to high-power models. Our product range includes Brushless DC Motors, Battery-Driven AC Servo Motors, Geared Motors, In-Wheel Motors, and Cooling Fans. Beyond product supply, we deliver dedicated technical support—from driver selection and setup guidance to troubleshooting—ensuring seamless operational integration for our customers.
