Brushless Parallel Axis Geared Motor for Electronic Component Mounting
Optimize the cost of the substrate supply device. A planetary geared motor that achieves high torque with a simple design.
In the electronic component assembly industry, stable transport and precise positioning are required in substrate supply devices. Particularly in mass production lines composed of multiple axes, reliability that can withstand long-term continuous operation while keeping the cost of each unit down is essential. Excessive functionality leading to increased costs significantly burdens capital investment. Our PGM series achieves robust drive required for substrate supply units in assembly lines by specializing in the basic operations of rotating and stopping. 【Usage Scenarios】 - Transport drive for substrate supply conveyors - Substrate insertion units for assembly machines - Automated transport devices for mass production lines 【Benefits of Implementation】 - Reduction in equipment installation costs due to simple design - Compact and high-torque transport achieved by adopting planetary gears - Securing high price competitiveness in mass production projects
basic information
【Features】 - A wide lineup with rated output from 20W to 500W - High torque and space-saving design using planetary gears - Power supply options of DC24V, AC110V, and AC220V - Gear head shapes available in parallel shaft, hollow shaft, and orthogonal shaft - Dedicated driver (MLD/EHD/EBD/BHR series) for intuitive operation 【Our Strengths】 As a specialized company handling a wide range from low-voltage battery drives to AC servos, we support the selection of optimal motors and drivers. We accompany our customers through their design challenges, providing support from control settings after delivery to troubleshooting on-site, ensuring stable operation.
Price information
By stripping away excessive features and focusing on basic performance, we have achieved an overwhelmingly low price of "less than half the cost" compared to conventional domestic manufacturer equivalent products (brushless motor + planetary gear). The drastic cost reduction of the motor alone dramatically lowers the manufacturing cost of the entire equipment. Prices vary depending on the combination of voltage, output, gear shape, and driver, so please request a detailed estimate. It demonstrates its maximum effectiveness when implemented in bulk for mass production machinery (volume discount).
Delivery Time
Model number/Brand name
PGM Series
Applications/Examples of results
As a drive module that balances space-saving and high output, it is ideal for projects with strict budget and space constraints. 【Main Application Examples】 Manufacturing FA and automation equipment: Industrial machinery that requires reliable speed and torque control in limited space, such as small conveyor drives, index table rotation, lifters, and packaging machines. Small AGVs and automated transport robots: Standardly compatible with DC24V battery drive. Used as a drive axis or power source for small AGVs (automated guided vehicles) that autonomously navigate within factories and warehouses. Next-generation technology verification and testing environments: Contributing to rapid prototyping as a "mobility and drive source" incorporated into platforms for prototyping new mechanisms and conducting demonstration experiments. We respond to requests such as "I want to arrange the motors orthogonally according to the layout of the equipment" and "I want to procure the same motor cheaply in large quantities" with three types of gear shapes (parallel axis, L type, R type) and overwhelming cost advantages. Customizations during mass production, such as adding non-excited brakes, can also be flexibly accommodated.
Line up（5）
| Model number | overview |
|---|---|
| PGM60 Series | （□60mm / 20W・50W） |
| PGM80 series | （□80mm / 50W・75W・100W） |
| PGM90 Series | （□90mm / 75W・100W・150W・300W・500W） |
| PGM104 series | （□104mm / 150W・300W・500W） |
| All models | *All models allow you to choose from the gear head shapes of parallel axis (S1), hollow axis flat L type (S2), and orthogonal axis R type (S3). *We offer power supply specifications of DC24V, AC110V, and AC220V. |
catalog（4）
Download All Catalogs
Distributors
CLUW Inc. specializes in low-voltage battery-driven motors and control drivers, offering a comprehensive lineup from compact to high-power models. Our product range includes Brushless DC Motors, Battery-Driven AC Servo Motors, Geared Motors, In-Wheel Motors, and Cooling Fans. Beyond product supply, we deliver dedicated technical support—from driver selection and setup guidance to troubleshooting—ensuring seamless operational integration for our customers.
