Interference Check Using CADPAC-CREATOR for the Machinery Industry
Thoroughly check for interference during the design phase with 2D/3D integrated design CAD!
In the machinery industry, interference checks during the design phase are essential to ensure product quality and safety. Interference between parts can lead to assembly defects and product malfunctions, resulting in increased costs due to rework. CADPAC-CREATOR integrates 2D and 3D data to visualize interference during the design phase, addressing these issues. This allows designers to quickly and accurately identify interference points and make necessary corrections. 【Usage Scenarios】 - Design of mechanical components - Simulation of assembly processes - Creation of 3D models of products 【Benefits of Implementation】 - Reduction of design errors - Decrease in rework labor - Improvement in product quality
basic information
【Features】 - Achieves highly flexible 3D modeling through direct feature-based design - Supports the import of various 3D CAD data - Allows the use of 2D drawings as 3D sketches - User-friendly operation of domestically produced 2D CAD that has been chosen for over 30 years - Interface that supports everything from design to manufacturing 【Our Strengths】 Design and creation aim to make IT a tool for 'manufacturing' that anyone can use. We continue to develop all the necessary functions for the future of 'manufacturing,' from CAD/CAM to internet collaboration, and provide ongoing support for effective utilization, striving to become a new force that opens the 21st century.
Price information
Prices may vary depending on the system configuration. Please contact us for more details.
Delivery Time
Model number/Brand name
CADPAC-CREATOR
Applications/Examples of results
We have numerous implementation results, primarily in the manufacturing industry. For more details, please contact us.
