Easy-to-install metal detector 'Metalarm' for existing conveyors.
Easily install a metal detector on an existing conveyor belt without the need to cut the belt. Adjustments after installation are also simple, and no trial operation adjustment personnel are required!
- Our company uses a unique pulse detection coil that can be installed without cutting the conveyor belt, allowing for the detection of iron and other metals as well as conductors. - The coil is made of high-density polyethylene and is lightweight enough for one adult to lift, making it easy to handle. - It is suitable for outdoor use, resistant to wind and rain, and the coil part is almost maintenance-free. - A control panel is included as standard. The control panel is compliant with IP66 and NEMA4X for dust and water resistance. - We offer a variety of options, including a siren and patrol light for detection, an internal heater for cold climates, and a corrosion-resistant housing made of SUS304. - During detection, the relays for A contact and B contact are switched within the panel, allowing for easy external signal output. - Resetting after detection can be done manually, automatically, or via remote operation. - We will manufacture the shape to fit your conveyor design. We can also accommodate modifications such as drilling holes or notching for the mounting bracket. - It is also possible to customize the specifications to avoid detecting very small pieces of iron.
basic information
Type: Trough Coil / Bridge Coil Metal Detector Model: Metalarm 3500 Coil Dimensions: Effective detection width of 300mm to 2,400mm Weight: Ranges from a few kg to several tens of kg depending on dimensions Power Supply: 100 or 200V (with switch) / 50, 60Hz compatible, single-phase, power consumption 11W Detection Accuracy: Detects a φ5mm iron ball at maximum sensitivity and optimal position (this is influenced by surrounding environment, distance from the coil, and level of power supply noise. In outdoor or heavy-duty environments, it is common to install the device to detect larger iron pieces such as a 50mm square iron plate.) *For higher detection accuracy challenges, such as detecting metal particles below φ1mm, we recommend selecting one of our other models. Please feel free to contact us.
Price information
Prices may vary depending on specifications, so please feel free to contact us.
Price range
P4
Delivery Time
P4
Delivery dates may vary depending on specifications. Please feel free to consult with us.
Applications/Examples of results
- Installed on the belt conveyor of the coal transport equipment - Installed on the belt conveyor of the cement raw material receiving equipment - Installed after the magnetic separator of the crushed stone transport equipment - Installed on the ore transport conveyor of the limestone quarry - Installed after the magnetic separator of the wood recycling equipment - Installed at the final stage of the food packaging system - Other processes for detecting the intrusion of metal fragments
