High-performance TDR cable length measurement device 'CS90'

Quickly and accurately measure the cable length and fault details! The automatic fault detection feature speeds up the inspection.

The "CS90" is a high-performance TDR cable length measuring device capable of accurate measurement and diagnosis from a zero-meter starting point. It stores settings for commonly used cables in the main unit and is equipped with a momentary disconnection detection function that retains short-term disconnection faults in the waveform. Additionally, results can be saved, shared, and printed on a PC using dedicated software. 【Features】 ■ Accuracy ±0.01%, ultra-high-performance TDR ■ Rapid and accurate measurement of cable length and fault details ■ Automatic fault point detection function accelerates inspection ■ Measurement results can be saved to a PC via SD card or USB *For more details, please download the PDF or feel free to contact us.

basic information

【Other Features】 ■ Accurate length measurement and diagnosis from the zero-meter starting point ■ Storage of frequently used cable settings in the main unit ■ Momentary disconnection detection function that leaves short-term disconnection faults on the waveform ■ Save, share, and print results on a PC using dedicated software *For more details, please download the PDF or feel free to contact us.
