[Free Demo Unit] Advanced Movable Industrial Endoscope Video Inspector 3DX
A fiber scope that can be freely maneuvered 360° with a twist. Intuitive operation with a joystick.
Intuitive operation of the camera cable tip with a joystick. Still images and video resolution are in HD quality at 1280×720 pixels, achieving high-precision inspections. The waterproof (marine-compatible) and oil-resistant cable tip is equipped with eight LEDs. It comes with a magnetic holder mount, allowing the main unit to be installed on magnetic surfaces.
basic information
Camera head/cable: Diameter 9mm, 1m Curvature angle: 360° direction, maximum 150° (tolerance ±10°) Display: 3.5-inch TFT color monitor Display resolution: 640×480 pixels Still image/video resolution: 1280×720 pixels Field of view: 90° Focal length: 1.5 to 10cm Image format: JPEG, MJPG (AVI) Recording media: MicroSD card (up to 32GB) LED: 8 units (4 levels of brightness) Zoom: 2x Protection performance: Body: IP54, cable: IP67, cable can be used with diesel, gasoline, engine oil, AdBlue, ethyl alcohol, saltwater (salt content 28%) Power supply: Lithium-ion rechargeable battery (built-in) Operating time/charging time: Approximately 5 hours/approximately 3 hours Operating environment: -10 to 45°C, humidity <80% rH, no condensation, altitude <2000m Storage environment: -10 to 60°C, humidity <80% rH, no condensation Size/weight: 108×260×110mm (including holder)/810g (including cable)
Price information
¥240,000 (including tax ¥264,000)
Price range
P3
Delivery Time
P1
Model number/Brand name
Laser liner
Applications/Examples of results
●Engine room ●Inside machinery ●Piping ●Drainage ditch ●Water facilities ●Air conditioning equipment ●Attic inspection ●Search and rescue operations under rubble
