Industrial computer
Achieves low power consumption comparable to a laptop and expandability comparable to a desktop computer. Designed with consideration for use in harsh conditions, it offers high durability.
Using the 8th generation Intel mobile Core i5-8365UE Quad Core / 4.1GHz (Burst) / 1.8GHz 6MB cache. It allows for replacement with an 11th generation CPU, ensuring long-term stable supply. - Customization of specifications is possible upon request. - Replacement with the latest CPUs or low-cost CPUs is possible.
basic information
Main Specifications 1. CPU: 8th Generation Intel Mobile Core i5-8365UE Quad Core / 4.1GHz (Burst) / 1.8GHz 6MB cache 2. Installed Memory: Up to 32GB Dual Channel DDR4 3. Boot Disk: Serial ATA SSD (240GB) 4. Serial Port: RS-232C/2ch (Rear Option) 5. LAN: 10/100/1000base-T/2port (Rear) 6. USB: USB3.0/4port (Rear), USB2.0/4port (Front) 7. Display I/F: HDMI 2port (Rear) 8. Serial ATA: 3port / 2port 9. Expansion Slots: PCI Express X4 1 slot, X1 2 slots 10. Power Remote Terminal: Terminal block connector for remote ON/OFF control of power 11. Power Supply: AC 85V–264V 12. Dimensions: 155mm (W) × 262mm (D) × 240mm (H) 13. Temperature & Humidity: Operating: 5℃ to +40℃ 14. Supported OS: Windows 10 IoT LTSC 2021
Price information
Separate consultation required. It depends on the specifications and quantity requested.
Delivery Time
Applications/Examples of results
Device control, image processing
