A secret that only those who have done copper welding can understand...
The secret of copper welding that I will only teach to you who have been seen.
Product Introduction Our company adopts "TIG welding" to accommodate various shapes and plate thicknesses. TIG welding is a technique that uses approximately 100A to 180A of electric heat and inert gas to melt the joining parts of the materials and manually join them. Copper's excellent conductivity can be a disadvantage in welding, as the electricity flowing through the weld can be transmitted in all directions. Therefore, it is necessary to have the experience to visually assess the melting of the materials and determine whether they are being welded, as electricity does not accumulate at the joint. To achieve high-quality welding, it is crucial to manage temperature through uniform preheating, temperature measurement, and welding; it is not an exaggeration to say that the quality of welding is determined by the preheating! Welding allows for sizes that exceed the width of commercially available copper busbars and enables shapes that can only be achieved through welding, thus expanding the range of product shapes. "I wonder if we can make this shape...?" Please feel free to consult with us. In addition, we have a wide range of processing achievements for copper busbar products with thicknesses from 3mm to 20mm for transformer manufacturers and panel manufacturers in the Tokai region, processing 150 tons of copper annually as a specialized copper processing company. We have a consistent production system from order to processing, plating, and delivery/shipping, allowing us to respond quickly with drawings and order forms!
basic information
【Specifications】 Material: C1100-1/2H (Tough Pitch Copper) Supported Plate Thickness: 3mm to 20mm Maximum Width: 150mm (200mm processing available for 10mm, 12mm, and 15mm) Maximum Length: 2000mm, negotiable Processing Details: Press punching, press bending, machining, lathe processing Surface Treatment: Tin plating, silver plating, nickel plating available Order Quantity: Welcomed from 1 piece! Delivery Time: Approximately 1 week or more
Price range
Delivery Time
Model number/Brand name
ishigaki-Cu-busber
Applications/Examples of results
Applications Incorporation achievements - Oil-filled transformers - Molded transformers - Cubicles - Distribution boards and control panels - Current-carrying components for machine tools such as spot welding machines and plating equipment
catalog（4）
Download All Catalogs
Recommended products
Distributors
We have been providing copper components to transformer and control panel manufacturers, delivering energy through copper and ensuring safety and security for society. As a result of walking alongside our customers throughout this process, we have become a "copper specialty processing company"! When our customers are truly in need, we respond as quickly as the same day, embodying the spirit of mutual support! ■ Overwhelming inventory ■ Craftsmanship that allows for the fastest processing and youthful, energetic power ■ Strong network with local plating partner companies We can perform various processing methods such as machining, pressing, welding, and brazing. Since we have established a production system for a wide variety of small quantities, ■ Small lots ■ Various sizes ■ Complex shapes can also be handled quickly. We aim to be a company that delivers energy to everyone through copper, and we look forward to your continued support.
