Great performance even at substation-level high voltage! 10mm copper busbar!
10mm copper busbar that controls huge voltage!
The 10mm copper busbar is a copper busbar designed to control large currents ranging from approximately 1000A to 2200A! It is mainly used in substations and, more recently, seems to be installed in server racks at AI data centers. Ishigaki Shoten has completely transferred the technology, know-how, and equipment for the in-house production of copper busbars from a transformer manufacturer in the Tokai region, which is a group company of a power company, allowing us to excel in the production of copper busbars tailored to a wide range of voltages from 3mm to 15mm. In addition, we have a wide range of processing achievements for copper busbar products with thicknesses from 3mm to 20mm for transformer manufacturers and panel manufacturers in the Tokai region, processing as much as 150 tons of copper annually as a specialized copper processing company. Our integrated production system covers everything from order receipt to processing, plating, and delivery/shipping, allowing us to respond quickly with drawings and order forms! Hand-drawn designs are acceptable! We can handle orders starting from just one piece! Urgent requests are welcome! Please feel free to consult with us!
basic information
【Specifications】 Material: C1100-1/2H (Tough Pitch Copper) Supported Thickness: 3mm to 20mm Maximum Width: 150mm (Processing records available for widths of 200mm for 10mm, 12mm, and 15mm) Maximum Length: 2000mm (Negotiable) Processing Details: Press punching, press bending, machining, lathe processing Surface Treatment: Tin plating, silver plating, nickel plating available Order Quantity: Welcomed from 1 piece! Delivery Time: Approximately 1 week~
Price range
Delivery Time
Model number/Brand name
ishigaki-Cu-busbar
Applications/Examples of results
Applications Incorporation achievements - Oil-filled transformers - Molded transformers - Cubicles - Distribution boards and control panels - Electrically conductive components for machine tools such as spot welding machines and plating equipment
Recommended products
Distributors
We have been providing copper components to transformer and control panel manufacturers, delivering energy through copper and ensuring safety and security for society. As a result of walking alongside our customers throughout this process, we have become a "copper specialty processing company"! When our customers are truly in need, we respond as quickly as the same day, embodying the spirit of mutual support! ■ Overwhelming inventory ■ Craftsmanship that allows for the fastest processing and youthful, energetic power ■ Strong network with local plating partner companies We can perform various processing methods such as machining, pressing, welding, and brazing. Since we have established a production system for a wide variety of small quantities, ■ Small lots ■ Various sizes ■ Complex shapes can also be handled quickly. We aim to be a company that delivers energy to everyone through copper, and we look forward to your continued support.
