3D Profilometer Technical Documentation: Research on Welded Surfaces
This is a PDF document on "Research on Welded Surfaces." Please download it for details.
For specific areas of welding, visual inspection is usually conducted; however, there may be cases where extremely precise investigation is essential. The specific areas subject to detailed analysis include surface cracks, porosity, and un-welded craters, regardless of subsequent inspection procedures. Welding characteristics such as dimensions, shape, volume, roughness, and size are all necessary for evaluation. Moreover, these parameters are measurable.
basic information
◎Real Nano 3D Profilometer for Surface Characterization Nanovia's Real Nano 3D surface inspection device provides high-precision surface characterization for "roughness measurement," "texture analysis," and "step and height evaluation." The non-contact profilometer, utilizing advanced chromatic light technology, offers reproducible high-resolution surface measurements across a wide range of applications, including "coatings," "semiconductors," "medical devices," and "aerospace materials."
Price range
Delivery Time
Model number/Brand name
Nanovia 3D Profilometer
Applications/Examples of results
◎ 400mm² × 200mm/s high-speed continuous scanning ◎ Unique new method by Nanovia "Multicolor Light Sensor Measurement" ◎ "Vertical Focus" measured data without stitching
