COM Express Type 6COM-ARHC6
Miniaturizing high-performance x86. Ideal for edge AI and control applications.
COM-ARHC6 is a high-performance and highly expandable embedded module provided by AAEON, featuring the Intel Core Ultra (200H series) processor in a COM Express Type-6 (compact size 95×95 mm) module.
basic information
●95mm x 95mm ●Equipped with Intel Core Ultra 5 225H/Ultra 7 255H/Ultra 9 285H ●DDR5 6400MHz SODIMM×2 (maximum 128GB) (sold separately) ●VGA×1, LVDS/eDP×1, DDI×3 ●USB 2.0×8, USB 3.2 Gen2×4 ●PCIe [x1]×4, PCIe [x4]×1, PEG [x8]+[x4]+[x4] ●Intel Ethernet Controller I226 (2.5GbE×1) ●Power input: 9V–16V ●COM Express Type 6, 3.75”×3.75” (95mm×95mm) ●Operating temperature 0~60℃
Price range
Delivery Time
Model number/Brand name
COM-ARHC6 AAEON
Applications/Examples of results
Industrial HMI / Control Terminals Gateway / Edge AI Processing Digital Signage Smart Retail Terminals Embedded Devices such as Medical and Inspection Equipment
