Self-rotating stirring and degassing mixer high-low rotor series, tabletop & variable ratio type.
Here is a high-spec stirring and defoaming mixer that can be used in a space-saving manner!
The conventional High-Rotor series is a high-speed rotary type with a focus on dispersion force and a self-rotation to revolution ratio of 2:1. However, this variable self-rotation and revolution ratio RS type High-Rotor has been developed as a high-spec model that allows independent adjustment of the rotation speed for self-rotation and revolution in 1 rpm increments. Not only is the 2:1 ratio for high-speed self-rotation possible, but settings that emphasize centrifugal force for high-speed revolution can also be achieved, enabling the reproduction of dispersion and defoaming conditions from other manufacturers. Additionally, it is the first tabletop size in the High-Rotor series, allowing for dispersion and defoaming tasks to be performed without taking up space in cramped research labs or manufacturing sites. 【Features】 1) The 2:1 ratio for high-speed self-rotation is only possible with the High-Rotor. 2) The ratio for high-speed revolution is also possible, accommodating defoaming without vacuum, low-viscosity materials, and materials that are sensitive to temperature increases. 3) It is compact and does not take up much space. 4) It inherits the quietness and durability from the conventional High-Rotor. 5) This RS model also has a 10L container version available, making it easy to scale up.
basic information
【Specifications】 1) Container used: 300ml commercial PE container (various smaller containers can be used) 2) Size: □43cm × H61cm, 50kg (vacuum pump is separate) 3) Achievable vacuum level: 40Pa (absolute vacuum) 4) Power supply: Single-phase 100V 5) Rotational speed: Orbital Max 2000rpm, Rotational Max 2500rpm
Price range
Delivery Time
Model number/Brand name
HR003-02VRS mini
Applications/Examples of results
Purpose: This is a mixer used for simultaneously dispersing liquids and powders in liquids while degassing. Examples of use: Electronic material pastes, conductive and insulating pastes, thermal grease, abrasives, sealing materials, molding materials, adhesive materials, electrode pastes, ink materials, coating liquids, cosmetic bases, dental materials, medical and pharmaceutical materials, etc.
Line up（1）
| Model number | overview |
|---|---|
| HR003-02VRS mini |
