Self-rotating stirring and defoaming mixer high-low rotor series 10L & variable ratio
We can propose a high-spec 4-cup stirring and defoaming mixer even from a mass production perspective!
The conventional high-rotor series is a high-speed rotation type with a focus on dispersion force and a self-rotation to revolution ratio of 2:1. However, this variable ratio RS type high-rotor has been developed as a high-spec model that allows independent adjustment of the rotation speeds for self-rotation and revolution in 1 rpm increments. Not only does it maintain the 2:1 ratio for high-speed self-rotation, but it also allows for settings that emphasize centrifugal force during revolution, making it possible to replicate the dispersion and degassing conditions of other manufacturers. Developed as a highly demanded 10L type for mass production, it retains the ability to accommodate four containers while being a variable ratio model. During the transition from research and development to mass production, necessary efforts and considerations can be reduced. Additionally, we can flexibly accommodate customizations such as explosion-proof features, cooling, and special containers. 【Features】 1) The 2:1 ratio for high-speed self-rotation is only possible with the high-rotor. 2) The ratio for high-speed revolution is also possible, accommodating degassing without vacuum, low-viscosity materials, and materials that are sensitive to temperature increases. 3) Customizations are available; please consult us. 4) Quietness and durability are inherited from the conventional high-rotor. 5) Scaling up from small mixers used in research and development is easily achievable.
basic information
【Specifications】 1) Container used: 10L commercial SUS container (custom resin containers are also possible; a wide variety of containers can be used if smaller than the above) 2) Size: 200cm × 135cm × H145cm, 3000kg (vacuum pump is separate) 3) Achievable vacuum level: 100Pa (absolute vacuum) 4) Power supply: Three-phase 200V 5) Rotational speed: Orbital max 700rpm, axial max 700rpm
Price range
Delivery Time
Model number/Brand name
HR100-04VRS
Applications/Examples of results
Purpose: This is a mixer used for simultaneously dispersing liquids and powders in liquids while also degassing. Examples of use: Electronic material pastes, conductive and insulating pastes, thermal grease, abrasives, sealants, molding materials, adhesive materials, electrode pastes, inks, coating liquids, cosmetic bases, dental materials, medical and pharmaceutical materials, etc.
Line up（1）
| Model number | overview |
|---|---|
| HR100-04VRS |
catalog（1）
