2-axis screw pump 'Bornemann' ┃ hygienic specification
Low shear & low pulsation pumps for food, pharmaceuticals, cosmetics, and chemicals. Capable of transporting ultra-high viscosity liquids while suctioning without damaging solids. Maintenance is also easy.
"High viscosity liquids and hygiene, without compromise on either—" The twin-screw pump 'Bornemann SLH-5G' supports viscosities up to 1,000,000 cP. It achieves all the requirements for "high viscosity transport," "low shear," "cleanability," and "chemical resistance" demanded by the food, pharmaceutical, cosmetics, and chemical industries. The Bornemann SLH-5G series is a high-performance screw pump designed for hygiene, capable of handling all types of liquids with over 50 screw profiles and a wide range of material compositions. **Main Features** - Supports viscosities up to 1,000,000 cP: Capable of transporting chocolate, collagen, ice cream, and slurry liquids. - Hygiene design: CIP/SIP compatible, certified to 3A/EHEDG standards, parts can be disassembled for excellent cleanability. - Low shear transport: Minimizes product separation, destruction, and foaming, safe for pharmaceuticals and dairy products. - Wide flow range: Stable supply from small to large volumes. - Standard mechanical seal for shaft sealing: Prevents liquid leakage and improves maintenance. - Wear-resistant and chemical-resistant options: Capable of hard coating (1200HV). Compared to pumps with equivalent performance, it is recognized for its wide adaptability from low to ultra-high viscosity and high cleanability, leading to widespread adoption, particularly in Europe.
basic information
▶ For inquiries regarding testing and specification selection with actual liquids, please contact us here. ▶ Please consider starting with the catalog download. 【Compatible Viscosity】Up to 1,000,000 cP 【Hygiene Standards】Compliant with 3A / EHEDG / FDA 【Maximum Pressure】2.5 MPa 【Maximum Rotational Speed】3,000 rpm 【Sealing Method】Mechanical seal / 3-part design 【Cleanability】Easy to disassemble / CIP compatible
Price information
For details, please contact us. Estimates will be provided on a case-by-case basis.
Delivery Time
Applications/Examples of results
- Tomato Industry Product: Cut Tomatoes, Flow Rate: 25㎥/h, Differential Pressure: 1.0MPa, Viscosity: 7,000cst (with modification) - Dairy Industry Product: Hazelnut Chocolate, Flow Rate: 2㎥/h, Differential Pressure: 0.7MPa, Viscosity: 200,000cst - Cheese Industry Product: Processed Cheese, Flow Rate: 1㎥/h, Differential Pressure: 0.6MPa, Viscosity: 1,000cst - Beverage Industry Product: Fruit Juice and Concentrate, Flow Rate: 40㎥/h, Differential Pressure: 1.5MPa, Viscosity: 8cst - Pharmaceutical Industry Product: Collagen, Flow Rate: 2.4ℓ/h, Differential Pressure: 2.0MPa, Viscosity: 20,000cst - Ice Cream Industry Product: Ice Cream and Fruit Pieces, Flow Rate: 40 packs × 0.5ℓ/min, Differential Pressure: 0.2MPa, Viscosity: 20,000cst
Detailed information
-
The SLH series two-axis screw pump is a volumetric pump that transports products along the axis using two screws. Despite being non-contact, the very narrow clearance between the conveying screw and the inner surface of the casing forms a sealed chamber, allowing for continuous transfer of the product from suction to discharge.
-
To improve cleanability, the casing is separable.
-
SLH-4G 6000 in Dairy Production Line Tomato Industry User Benefits: Gentle Liquid Transfer Pump Model: SLH-4S 6000 Product: Diced Tomatoes Flow Rate: 25m3/h Differential Pressure: 10 bar Viscosity: 7,000cSt – Thixotropic
-
SLH-4S 3000 in Beverage Production
