Semi-automatic assembly device
Assemble the syringe body and plunger in a single operation!
We would like to introduce the "semi-automatic assembly device" that we handle. This device is a semi-automatic assembly machine that assembles the syringe body and plunger during the assembly process of syringe components. It supplies and aligns the syringes, transports the plunger to the designated position, and inserts it in the correct orientation. With the work positioning guide and insertion support mechanism, it suppresses posture misalignment and assembly variation during insertion. Operation, stop, and manual control are possible via a touch panel, and the operating status can be easily confirmed through status displays and alarm notifications. 【Features】 - Reduces the burden on operators by automating assembly work - Standardizes processes and stabilizes assembly quality - Reduces variation in manual work and decreases defects - Improves productivity through automation from supply to discharge - Equipped with safety features such as emergency stop and cover open detection *For more details, please download the PDF or feel free to contact us.
basic information
【Flow of Semi-Automatic Assembly】 1. Syringe Supply: Supply syringes one by one cut from those placed in the hopper. 2. Transport and Positioning: Transport syringes with pitch feeding and accurately position them at the insertion point. 3. Plunger Supply: Retrieve plungers from the supply section and transport them to the insertion point. 4. Plunger Insertion: Insert the plunger into the syringe using an actuator. 5. Finished Product Discharge: Discharge the assembled products to the discharge position. *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
