High durability! Sliding door closer "Sliding Closer CF Series"
During normal opening and closing, quiet operation and high durability are ensured! In the event of a fire, the door is supported by stainless steel auxiliary rails and auxiliary rollers.
The sliding closer is a specialized closer for sliding doors that opens lightly with a small force and closes quietly and reliably at your preferred speed. The CF series adopts a double rail specification for fire doors, supporting the door even during a fire. *This product is not certified as a fire protection device or a specific fire protection device (it cannot be certified as a closer alone). When using it for fire doors, please obtain individual ministerial certification or use it based on the structural specifications outlined in the Ministry of Construction notice. *For product details, please refer to the PDF materials or feel free to contact us.
basic information
【Example Specifications】 Model: DSC-C08F-22 Applicable door weight: 30–80kg Applicable door width: 700–1200mm Maximum stroke: 1500mm Closing drive method: Rail incline (3.5/300) Braking method: Fluid friction resistance type Braking time: 7–11 seconds (at an opening distance of 900mm) Initial opening force: 5.4N (door weight 30kg), 12.5N (door weight 80kg) Durability: Over 1 million open/close cycles Braking device model: SC-C08F Standard rail length: 2.2m
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
