【For Airports】Efficiency Improvement of Loading and Unloading Operations BFV203
Enhancing safety at airport logistics sites where people and vehicles intersect.
In the cargo area and backyards of airports, truck movements and loading operations are carried out daily. There are many situations where checking the surroundings is crucial, such as when reversing or approaching other vehicles, and drivers are required to ensure safety. The BFV-203 is a collision warning system that detects people around the vehicle using cameras and AI technology. When it detects an intrusion into a designated danger area, it warns the driver with audio and visual alerts. It supplements blind spots that cannot be fully understood through visual checks or mirrors, supporting safety checks during on-site driving and loading operations. This product has been selected as an eligible device for subsidies from the All Japan Trucking Association. By balancing safety improvements with reduced implementation burdens, it contributes to stable operations and the creation of a safe working environment in airport logistics. *Please check the latest information for detailed conditions of the program. [Usage Scenarios] - On-site driving in airport cargo areas - Loading and unloading operations in front of warehouses - Surroundings of backyards and waiting areas [Effects of Implementation] - Complements checks around trucks, reducing the risk of contact and collision accidents - Supports drivers in safety checks, enhancing the sense of security at the site
basic information
【Function】 Detection Targets: Pedestrians, people riding motorcycles/bicycles, etc. Detection Range: Approximately 7m in front to approximately 12m behind (varies depending on installation position) Detection Environment: Illumination of approximately 15 lux or more (around streetlight level at night) 【Identification Unit】 Power Consumption: Approximately 7.5W Input: +4/-1 (vehicle speed pulse) Output: FET +2 (maximum 0.2A, with overcurrent protection) Permissible Voltage: +60V Dimensions & Weight: 157.8×89.4×43.5mm / approximately 780g Temperature Range: Operating -20 to +65℃, Storage -40 to +90℃ 【Camera】 NTSC/CMOS approximately 350,000 pixels Dimensions & Weight: 23×23×32.6mm / approximately 54g Temperature: Operating -20 to +70℃, Storage -30 to +80℃ 【Indicator】 Warning: Red LED 15×20mm Status: Red LED φ3mm Dimensions & Weight: 35×12×75mm / approximately 20g 【Monitor】 NTSC/7 inches (154×86mm) Dimensions & Weight: 174×125×27mm / approximately 0.5kg Temperature: Operating -10 to +60℃, Storage -20 to +70℃
Price range
Delivery Time
Model number/Brand name
BFV203
Applications/Examples of results
- The AI automatically recognizes pedestrians, bicycles, and motorcycles entering the side or rear of the truck while in motion. It captures movements in positions that are difficult to see in mirrors, enabling early detection of contact or entrapment risks. - The moment a detection occurs, it alerts the driver through audio and screen displays inside the vehicle. This helps compensate for oversight or delayed judgment, serving as a safety support to prevent accidents before they happen. - It detects the approach of workers in logistics centers, on-site yards, and loading areas. It supports safety checks in particularly dangerous situations, such as during reversing or maneuvering. - It can reliably detect even in nighttime or dimly lit areas (with illumination above 15 Lux). It accommodates a wide range of operating hours, including early morning departures and late-night deliveries.
