BFV202 Smart Installation Forklift Safety Support System
Safety measures for forklifts that change retroactively.
The BFV202 features a compact design that is small and lightweight, making it easy to fit into limited spaces and allowing for hassle-free installation that takes into account the vehicle's structure and layout. It is also easy to retrofit, enabling smooth integration into existing vehicles. Additionally, its simple structure enhances workability, allowing for quick installation without the need for extensive construction. The compact housing minimizes interference with operations and is designed to reduce impact on visibility while driving. Furthermore, various settings can be easily adjusted without the need to download a dedicated app, allowing for convenient access from tablets, PCs, or smartphones. This facilitates flexible implementation tailored to on-site operations, enabling smooth operation to begin while minimizing equipment downtime.
basic information
【Function】 Detection Target: Pedestrians (approximately 12m) Detection Range: The detection range can be set arbitrarily Front and rear of the forklift 0.5m to 12m Detection Area: 2 areas (Danger Area / Detection Area) 【Identification Unit】 Power Supply (Power Consumption): DC9-16V (standard) DC9-72V (optional) / 6W-7W Camera Input: NTSC: 4ch (switchable between 2ch forward and 2ch rear based on direction) Mounting Angle: -35° to -55° Monitor Output: NTSC: 1ch Dimensions: 156 (W) × 48 (H) × 112 (D) mm (excluding protrusions) Temperature (Operating) -30 to +60℃ (Storage) 30 to +80℃ 【Camera】 Type: NTSC / CMOS Dimensions: 23 (W) × 23 (H) × 32.6 (D) mm / approximately 54g Temperature: -20 to +70℃ 【Monitor】 Warning Display: Highlights the detected subject with a red frame and orange color Dimensions / Weight: 181 (W) × 134 (H) × 28 (D) mm / 860g (monitor body) Operating Ambient Temperature: -10°C to 60°C 【Speaker】 Dimensions / Weight: Diameter φ152mm × Total Length 178mm / 1.2kg Operating Temperature Range: -20℃ to +55℃
Price range
Delivery Time
Model number/Brand name
BFV202
Applications/Examples of results
【Purpose】 - Prevention of contact and entrapment accidents during forklift operation and loading/unloading tasks - Assistance with blind spots for drivers and support for visual confirmation - Utilization as a tool for safety education and improvement of the work environment
