Inline process analyzer UV meter / colorimeter / turbidity meter
Over 55,000 sets used worldwide for over 20 years, inline process analyzers (UV meters / colorimeters / turbidity meters).
【Features】 ■ Real-time measurement and monitoring ■ Quality control and standardization ■ Quantification of "appearance" color and turbidity ■ Reduction of management costs ■ Supports measurement of pH and conductivity ■ Compatibility with certain gases is also possible For more details, please refer to the catalog or feel free to contact us.
basic information
【Device Configuration and Lineup】 Optek's inline process analyzers consist of "sensors," "measurement cells," "converters," and cables and peripheral parts. 【Sensors】 ■ Turbidimeters, Colorimeters, UV Meters ・ Turbidity is measured by detecting scattered light and absorbance. ・ Color and UV are measured by detecting absorbance. ・ Visible light, near-infrared light, and ultraviolet light are used as light sources. ■ Conductivity Meters, pH Meters ・ Conductivity and pH can be measured directly within the piping. 【Measurement Cells】 ■ "Piping type" that sandwiches the sensor part within the piping and "Probe type" that inserts the sensor part into pipes or tanks. ■ Can be selected according to application. 【Converters】 ■ Field display type dedicated to process analyzers. ■ Capable of handling input related to measurement conditions such as temperature and pressure, along with output of measurement data.
Price range
Delivery Time
Model number/Brand name
Optek Corporation Inline Color and Turbidity Measurement System for Processes
Applications/Examples of results
**Applications for Pharmaceuticals and Biotechnology** - Absorbance/Turbidity of Bioreactors - Turbidity Monitoring of Centrifuges - Turbidity Measurement and Protein Concentration Measurement during Ultrafiltration and TFF - Protein Concentration after Chromatography Columns - Turbidity and Concentration Management during Drug Mixing and Dilution **Applications for the Chemical Industry** - Concentration Management through Color Measurement - Various Color Scales (e.g., APHA, Saybolt, HAZEN, ASTM, Gardner) - Filtration Leak Monitoring, Optimization of Backwashing - Leak Detection in Heat Exchangers - Phase Separation and Interface Detection: Emulsion (Mixed Phase) Detection in Tanks and Pipelines **Applications for Food, Beverage, and Beer** - Filtration Monitoring - Concentration Monitoring and Process Optimization through Color Measurement (e.g., Edible Oils (Yellowness, Red Phosphorus Concentration, Chlorophyll Concentration), Sugar Liquids (ICUMSA, RBU)) - Phase Separation and Interface Detection: Emulsion (Mixed Phase) Detection in Tanks and Pipelines - Yeast Management, Turbidity Monitoring during Brewing **Applications for Petrochemicals** - Color of Refined Fuels - Monitoring of Distillation Equipment The above are just examples, so please feel free to contact us for more details.
