Norway-born high-precision acrylic processing single-flute carbide end mill
Achieves high-precision machining without melting or burrs while maintaining excellent transparency.
The Crown single-blade carbide solid end mill, born in Norway, was developed for acrylic processing. With a wide variety and designed for high performance to meet the needs of production sites, it achieves high efficiency and high precision machining.
basic information
【Ultra-hard Solid End Mill for Acrylic Processing】 - Achieves high-precision finishing with a unique blade shape. - The unique flute shape allows for excellent chip evacuation, resulting in a high-quality surface finish. S1A Upcut Right-hand blade, right-hand twist, twist angle 23° With a wide variety and long blade length, it provides a seamless flat finish. S1AGEN Upcut Improved version of S1A for higher precision, twist angle 25° Recommended for use with high-precision spindles operating at 15,000 to 60,000 rpm. S1ADC Downcut Right-hand blade, left-hand twist, twist angle 23° The left-hand twist design prevents the workpiece from lifting, making it ideal for achieving a clean finish without chipping the top surface. 【Single Crystal Diamond Tool】 - Developed specifically for acrylic (extruded and cast materials). - Capable of achieving a clear surface finish with high transparency similar to glass on acrylic materials. MCD For side processing MCD90 45° single angle, for chamfering MCD0460 30° single angle, for engraving MCD0490 45° single angle, for chamfering/engraving
Price range
P2
Delivery Time
OTHER
For more details, please contact your nearest retailer.
Model number/Brand name
CROWN
Applications/Examples of results
This is a tool optimized for acrylic processing. It specializes in cutting, peripheral and groove processing, and engraving of resins, including acrylic (PMMA). It maximizes chip discharge for easily meltable acrylic, achieving a high-precision finish without burrs, whitening, or unevenness.
Related Videos
Line up（4）
| Model number | overview |
|---|---|
| S1A Upcut | Right-hand, right-twisted single-flute end mill that discharges chips upwards; a standard single-flute end mill with excellent finishing on the bottom and sides. |
| A1AGEN2 Uppercut | Higher precision specifications than S1A. Achieves even more precise and higher transparency finishes due to the special blade shape. For high-precision spindles ranging from 15,000 to 60,000 rpm, this is recommended. |
| S1ADC Down Cut | Right-hand cutting, left-hand spiral single-flute end mill. It is suitable for achieving a particularly clean finish on the top surface of acrylic sheets while pushing the chips downward during processing. |
| Acrylic-specific single crystal diamond tool | It is possible to achieve a clear surface finish with high transparency similar to glass on acrylic material. It is suitable for side processing (MCD), bevel processing (MCD90, MCD0490), and engraving processing (MCD0460, MCD0490). |
