UHF Band RFID Seal Type Temperature Logger Tag 'AZN5200'
Cold chain (fresh food, pharmaceuticals) / Temperature management for industrial applications! Seal-type temperature logger tags utilizing RFID technology.
The AZN5200 is a seal-type temperature logger tag that utilizes UHF band RFID technology. It accurately measures temperatures in the range of -30°C to +65°C and can automatically record data at regular intervals in its built-in memory, making it suitable for temperature traceability in cold chains and precision logistics. Its slim and flexible design allows for easy management by directly adhering it to cardboard boxes, plastic containers, pallets, and more. Equipped with FingerSpot (Touch Point), it allows users to start logging simply by touching it with a fingertip, simplifying operations on-site. Additionally, the LED visual indicator enables intuitive confirmation of conditions such as temperature deviations and tampering detection. The built-in battery supports the storage of thousands of logs, and data can be read non-contact and quickly with a standard RAIN RFID reader. The AZN5200 is a solution that balances ease of use with high functionality, achieving efficiency and reliability in temperature management. *For more details, please view the PDF data by downloading the catalog.*
basic information
RFID Temperature Logger Tag AZN5200 Temperature Range: -30° to +65° Number of Temperature Records: 4,096 Temperature Recording Time: Configurable from 30 seconds to 8 hours (Example) 1 time per minute → 4,096 minutes = approximately 2.84 days 1 time per hour → 4,096 hours = approximately 170.67 days 1 time every 8 hours → approximately 1,365 days = approximately 3.74 years RFID Communication Standard: UHF Band EPC Class1 Gen2 (v2.0.1) Compliant with ISO/IEC 18000-63 Dimensions: 33mm x 100mm Equipped with Flash Memory, LED, and Finger Touch Point
Price range
Delivery Time
Model number/Brand name
AXZON AZN5200
Applications/Examples of results
Main Use Cases - Transportation Management of Pharmaceuticals and Biologics: Records any temperature deviations during the transportation of products that require strict temperature control, such as vaccines and biopharmaceuticals. - Freshness Management of Food and Beverages: Monitors temperature changes during the transportation and storage of perishable foods, frozen foods, and wines, helping to maintain quality. - Quality Control of Chemical Products: Used during the transportation of chemicals that need to be stored within a specific temperature range. The AZN5200 is a label-type sensor that can be peeled off and stuck on. It can be directly attached to product containers, recording temperature from the beginning to the end of transportation. It is used throughout the supply chain of products requiring temperature management to enhance the reliability and traceability of temperature control.
Related Videos
Line up（1）
| Model number | overview |
|---|---|
| UHF Band RFID Temperature Logger Tag AZN5200 Evaluation Kit (1W Reader, Antenna, Evaluation Software, AZN5200) |
