Slider-type sorter "High-speed sorting device"
Achieving high processing capability with a compact structure! Ideal equipment for sites requiring processing capability in the mid-speed range.
The "High-Speed Sorting Device" is a slider-type sorter that combines a compact structure with high processing capacity and low cost. It achieves a line speed of 1.2 m/s, completing a single sorting operation in just 0.2 seconds. It can process 300 items per minute when sorting into two rows. Unlike traditional slide shoe sorters widely used in the logistics industry, this device is suitable for environments that require mid-speed processing capabilities in sorting systems. 【Features】 ■ Achieves high processing capacity with a compact structure ■ A single sorting operation is completed in just 0.2 seconds ■ Utilizes precisely machined sprockets ■ Capable of processing 300 items per minute when sorting into two rows *For more details, please download the PDF or feel free to contact us.
basic information
【Specifications】 ■Single item weight: 20g to 5kg ■Dimensions: Less than 400mm in height and width ■Processing capacity: 300 items per minute (varies depending on the object) ■Arrangement: Can distribute freely to 2, 3, and 4 rows, as well as from 2 or 3 rows to 1 row ■Transport speed: 60m/min (standard), 70m/min (special specification) ■Control method: PLC (standalone), without PLC (controlled by a higher-level machine) ■Power: Air-driven or servo motor ■Weight: Approximately 200 to 300kg ■Features: Count sensor installed at the entrance, jam detection sensor at the exit *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Recommended Applicable Items】 ■Soft bags ■Pillows ■Books ■Biscuits ■Seasoning packets ■Fruits *For more details, please download the PDF or feel free to contact us.
