SCBR type Escylock
SC lock at the cable entry point! Shuts out water and dust!
This is the SC Lock cable gland that can be used for cable entry points. It has a highly reliable sealing function, allowing for a secure sealing effect with light tightening. It can be used in machine tools, industrial machinery, industrial robots, vehicles, ships, various plants, OA equipment, general electrical equipment, waterproof devices, lighting equipment, various display devices, sensors, limit switches, solenoid valves, pressure switches, distribution boards, control panels, sub-distribution boards, operation panels, control centers, and various cable wiring works.
basic information
SC Lock ● SCBR Type New lineup of metal cable glands Wide range of compatible cable diameters Features ● Each size accommodates a wide range of cable diameters ● High-strength/high-rigidity metal housing ● High waterproof and environmental resistance Applications Cable entry points for electrical equipment, outdoor lighting fixtures, distribution boards, cable entry points for control boxes Additionally, the SC Lock series offers a variety of variations in its lineup. ● SCT Type - UL compliant ■ The material is self-extinguishing, and the resin parts use UL 94V-0 certified materials. ■ UL-514B certified product. ● SCL Type - Flame retardant ■ The material is self-extinguishing, and the resin parts use UL 94V-0 certified materials. ● SC Type - Corrosion-resistant type ● SK Type - Lightweight type ● SCS Type - Screw-in type ● SCH Type - For fiber optic cables ● JPS Type - Joint protector ● SCF Type ● SCT-D Type ● SCHR Type ● SCL-WAS Type You can choose according to your application. Please contact us if you would like a sample.
Price information
-
Price range
P1
Delivery Time
P1
Model number/Brand name
Waterproof Connector SC Lock Series
Applications/Examples of results
■Main Industries in Use Machine tools, waterproof equipment, electrical equipment, other manufacturing industries, others ■Applications 1. Machine tools, industrial machinery, industrial robots, vehicles, ships, various plants 2. OA equipment, general electrical equipment, waterproof equipment, lighting fixtures, various display devices 3. Sensors, limit switches, solenoid valves, pressure switches 4. Distribution boards, control panels, sub-distribution boards, operation panels, control centers 5. Various cable wiring work
Detailed information
-
SK type It is a general-purpose type.
-
SCL type Available in three colors: black, gray, and ivory You can choose the SC connector to match the color of wiring cables and distribution boards.
-
SCT type It is UL compliant.
-
For harsh environments, please choose the corrosion-resistant SC type.
-
JPS type Usage example
-
SCL Type Installation Example Installation Case of SCL Type Lock
-
SC Type Installation Example Installation Example of SC Lock Type
Line up（7）
| Model number | overview |
|---|---|
| SK Type | Lightweight ■ Contributes to the lightweight design of equipment. ■ The cap has a built-in rubber sleeve, providing excellent workability. ■ It accommodates a wide range of cable widths and external diameters. |
| SCL Type | ■ The body color comes in three colors. You can choose a color based on the usage location and differentiate by cable type. The cap directly presses the rubber, hugging the cable for waterproofing, as well as strong cable clamping force and preventing loosening of the cap. ■ The material is self-extinguishing, using UL94V-0 certified materials for the resin parts. |
| SCT Type | UL compliant Corrosion-resistant Lightweight ■ There is a clicking sound when the cap is turned, providing a secure tightening feel. ■ The material is self-extinguishing, using UL94V-0 certified materials for the resin parts. ■ UL-514B certified product. |
| SC Type | Corrosion-resistant ■ Resistant to acids, alkalis, and other chemicals. ■ The cap directly presses the rubber, hugging the cable for waterproofing, as well as strong cable clamping force and preventing loosening of the cap. |
| SCS Type | Screw-in ■ A type that screws directly into the conduit (lock nut is not included). ■ The cap directly presses the rubber, hugging the cable for waterproofing, as well as strong cable clamping force and preventing loosening of the cap. ■ The material is self-extinguishing, using UL94V-0 certified materials for the resin parts. |
| SCF Type | ■ When the internal and external space of the housing is narrow, making it difficult to install the conventional SC lock, it can be fixed to the housing wall with M4 screws. ■ It ensures the same IP67 waterproof structure as the conventional series (excluding the screw part). ■ The material is self-extinguishing, using UL94V-0 certified materials for the resin parts. |
| SCHR Type | ■ While conventional products have a maximum operating temperature of 80℃, this product can be used up to 200℃ (continuous use at 120℃). ■ If a metal part is used in applications requiring heat resistance, it can substitute for a metal cable gland. ■ Compared to a metal cable gland of almost the same size, the product weight is reduced by about half. |
