Box dimension and weight measurement system 'BoxMetrix'
Measurement of width, depth, height, and weight takes just 2 seconds! Significantly reduces the burden of measurement work.
"BoxMetrix" is a box dimension and weight measurement system that automates the measurement of box size and weight, outputting width, depth, height, and weight within 2 seconds of placing the box. The output includes receipt printing, recording images and CSV files, as well as data transmission to external sources. Fast, accurate, and easy. This system streamlines logistics with image processing technology. 【Features】 ■ Accurate image processing with a high-resolution camera ■ High repeatability ■ Printing dimensions and weight with a receipt printer (optional) ■ Saving image data ■ Saving to CSV files (Excel) ■ Integration with external devices and applications (optional) *For more details, please refer to the related links or feel free to contact us.
basic information
【Capabilities】 ■ Size measurement through image processing ■ Weight measurement (executed simultaneously with size measurement) ■ High-resolution image recording ■ Data recording to CSV files ■ Linking boxes and data via barcode reading or keyboard input ■ Printing measurement date and time, measurement data (W/D/H, weight) to a receipt printer (optional) ■ Communication with external systems via RS-232C/Socket (TCP/IP) (optional) *For more details, please refer to the related links or feel free to contact us.*
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the related links or feel free to contact us.
