Media Converter PLANET IGTP-805AT
Industrial media converter 1000BASE-SX/LX to 10/100/1000BASE-T 802.3at PoE+
Features ■ SFP module ■ Full-duplex operation with IEEE 802.3x flow control and half-duplex operation with backpressure ■ IP30 rated metal case ■ Wall mount and DIN rail ■ Supports 6000 VDC Ethernet ESD protection ■ Operating temperature -40 to 75°C ■ No external power cable required for installation
basic information
■Physical Port ・1000BASE-SX / LX to 10/100/1000BASE-T 802.3at PoE RJ45 interface ■PoE ・Compliant with IEEE 802.3at / PoE end-span/mid-span PD ・Maximum 30 watts PoE input ■Dimensions and Weight 135mm(W) x 87mm(D) x 32mm(H), 500g ■Environment Operating Temperature -40 to 75℃ Storage Temperature -40 to 85℃
Price information
Open price
Delivery Time
Model number/Brand name
IGTP-805AT
Applications/Examples of results
Cold outdoor, offshore, railway, ships, oil refinery, coal mine, pharmaceutical company, various factories, meteorological station.
Line up（3）
| Model number | overview |
|---|---|
| IGUP-805AT | Industrial 1-Port 100/1000X SFP to 1-Port 10/100/1000T 802.3bt PoE+ + Media Converter |
| IGTP-802T | 1000BASE-SX to 10/100/1000BASE-T 802.3at PoE+ Industrial Media Converter (SC,MM) -550m |
| IGTP-802TS | 1000BASE-LX to 10/100/1000BASE-T 802.3at PoE+ Industrial Media Converter (SC,SM) -10km |
