LoRaWAN bus passenger count, real-time monitoring kit for bus location.
Remote monitoring of bus location, cabin status, and passenger count via smartphone and PC, technical certification, long-distance communication, wide area, low power consumption LoRaWAN, compact and rugged enclosure.
Monitoring the bus's location, cabin status, and number of passengers using GPS, IP cameras, and passenger counting sensors. - UG65: Industrial LoRaWAN gateway that receives and transmits passenger count data from the VS121 passenger counting sensor and temperature and humidity data from the EM300-TH temperature and humidity sensor. - VS121: Industrial LoRaWAN AI passenger counting, occupancy detection, and dwell time detection sensor that transmits the number of passengers on the bus via LoRaWAN. - EM300-TH: Industrial LoRaWAN temperature and humidity sensor that transmits environmental data inside the bus via LoRaWAN. - UR35: Industrial cellular router that connects GPS and IP cameras to transmit the bus's location and cabin status via LTE.
basic information
【Temperature and Humidity Sensor EM300-TH-915M】 Temperature Range -30℃ to 70℃ Temperature Accuracy ±0.3℃ (0℃ to 70℃), ±0.3℃ (0℃ to 70℃) Humidity Range 0% to 100% RH Humidity Accuracy ±3% (10℃ to 90℃), ±0.5% (below 10, above 90) Battery Life 10 years (10-minute intervals) Protection IP67 Operating Temperature: -30 to 70℃ Dimensions 88.5x85.3x27mm Mounting Wall 【AI People Counting Sensor VS121-915M】 Field of View Horizontal 190° / Vertical 112° Recognition Range Radius 5m (Height 3m) Operating Temperature -5℃ to 55℃ Dimensions 85x85x20mm Mounting Ceiling 【Cellular Router UR35】 Cellular Antenna Connector 2×50Ω SMA Connector SIM Slot 2 (Mini SIM-2FF) Ethernet Ports 5×10/100Mbps PoE 2× 802.3 af/at PoE PSE on LAN Ports (Optional) Operating Temperature -40 to 70℃ Dimensions 135x103x45mm Mounting Desktop, Wall Mount, DIN Rail
Price information
Open price
Delivery Time
Model number/Brand name
UG65-L00J-915M-EA, VS121,EM300-TH、UR35・Milesight
Applications/Examples of results
Remote monitoring of bus location, cabin condition, and number of passengers.
