OSM CPU Module ADLINK OSM-MTK510
MediaTek Genio 510 SoC 2x Arm Cortex-A78 & 4x A55, LPDDR4 up to 4GB
【ADLINK OSM-MTK510 Features】 ■Dimensions: 45mm x 45mm ■Equipped with Genio 510 (Dual-core Cortex-A78 + Quad-core Cortex-A55) ■Includes Ethos U-VP6 AI processing unit ■Graphic output interfaces: HDMI/DisplayPort (DP), eDP, DSI ■LPDDR4 up to 4GB ■eMMC up to 128GB ■1x USB 3.0, 2x USB 2.0, 4x UART, 3x SPI, 2x I²S interfaces, 3x I²C interfaces, 17x GPIO ■RGMII LAN MAC interface supporting 10/100/1000 Mbps ■Complies with IEC 60068-2-64 and IEC-60068-2-27, MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
basic information
Specifications ■CPU: ・Genio 510 (Dual-core Cortex-A78 + Quad-core Cortex-A55) ・Equipped with Ethos U-VP6 AI processing unit ■Memory: LPDDR4 up to 4GB ■Storage: eMMC up to 128GB ■Ethernet: RGMII type LAN MAC interface supporting 10/100/1000 Mbps ■Interfaces: 1x USB 3.0, 2x USB 2.0, 4x UART, 3x SPI, 2x I²S interfaces, 3x I²C interfaces, 17x GPIO, HDMI/DisplayPort (DP, eDP, DSI) ■Power: 5V DC ■Operating temperature: 0°C to 60°C ■Dimensions: 45mm x 45mm
Price range
Delivery Time
Model number/Brand name
ADLINK OSM-MTK510
Applications/Examples of results
Factory and Building Automation / Control Systems / Communication Systems / Monitoring Systems
Line up（2）
| Model number | overview |
|---|---|
| OSM-MTK510-2G-32G-CT | OSM Size-L module with Genio 510 SOC , NPU , 2 GB LPDDR4, 32 GB eMMC, 0°C～ 70°C |
| OSM-MTK510-4G-32G-ER | OSM Size-L module with Genio 510 SOC , NPU , 4 GB LPDDR4, 32 GB eMMC, -40°C ～ 85° |
