28.6-inch Panel PC for Smart Transportation TS-286THD
28.6 inches, uses E-LED backlight, low power consumption, front waterproof IP65, capacitive touch, adopted for subway and electronic bus stop display boards.
【Techtion Smart TS-286THD Features】 ■28.6 inches, resolution 1920×560, E-LED ■Adopts IPS LCD for wide viewing angles, fast response, and high color reproduction ■Utilizes E-LED backlight technology for more uniform brightness ■High physical resolution of 1920×560 for finer image quality ■Wide viewing angle of 178° ensures nearly horizontal visibility ■Supports 24-hour continuous operation ■Uses LED backlight (MTBF: 50,000 hours) ■Industrial-grade design for high reliability, high stability, and low power consumption ■Supports RTC real-time clock, timer power on/off, and network wake-up ■Applications: Smart transportation (buses, subways, etc.)
basic information
Specifications - Panel: 28.6-inch wide E-LED display - Physical pixels: 1920×560 - Brightness: 350cd/m² - CPU: Cortex-A53*4@1.4GHz - GPU: ARMG31MP2 - DDR: 1G - EMMC: 8G/16G - OS: Android 9.0 - I/O connectors: RJ45×1, EARPHONE×1, HDMI×2, USB2.0×2, TF Card×2, SIM Card×1, AV IN×1 - Power supply: AC220V, 50/60Hz/DC9-36V (optional) - Power consumption: ≤35W - Standby: ≤1W - Dimensions / Weight: 752.3*249.2*60 mm / 7.0kg - Operating temperature: 0℃~60℃
Price range
Delivery Time
Model number/Brand name
Techtion Smart TS-286THD
Applications/Examples of results
Smart transportation (buses, subways, etc.), outdoor vending machines, outdoor transportation facilities (charging stations, tourist information signs, electronic bus stop display boards, etc.)
