36-screen split possible 27" LCD monitor CH-L270-2HDVSB
A security and monitoring monitor capable of displaying up to 36 IP camera feeds in a split view, featuring a high-resolution 27-inch wide LCD display and PoE support.
Features ■ H.264/H.265 compression format ■ Supports IP cameras up to 8MP ■ Graphical and text interface (GUI) ■ Supports Ethernet connection control ■ Supports HDMI/VGA/DVI-D input ■ Supports up to 36 network cameras via hub/switch ■ ONVIF compliant, supports Real-Time Streaming Protocol (RTP) ■ Security-grade metal housing. VESA standard compliant. ■ PoE compatible monitor
basic information
Specifications Screen Size: 27-inch Wide Display Area: 597.6 x 336.15mm Aspect Ratio: 16:9 Resolution (Max): 1920 x 1080 Display Colors: 16.7M Brightness: 300cd/m2 Viewing Angle: 89/89/89/89° Video Input: 1x HDMI / 1x VGA / 1x DVI-D Audio Input (R/L): 2x RCA Headphone Output: 1x Phone Jack 3.5mm Speakers: 2x Built-in Speakers (2W) Split Display Support: 1/2/4/6/8/9/10/16/25/36CH IP Video Support: 8MP/D1 Supported Decoding: H.264/H.265 Supported Protocols: ONVIF, RTSP, i9, SLINK protocol (*RTMP push, DDNS, UPNP, etc.) USB Ports: 2x USB 2.0 PoE Power Source: PoE RJ45 Ethernet Cable PoE Input Range (DC): 36–57V Hub/Switch PoE Requirement: Max 60W Power Consumption: Approximately 35W Dimensions: 658 x 396.5 x 63.9mm Weight: 7kg Operating Temperature: 0–50℃
Price information
Open price
Delivery Time
Model number/Brand name
CH-L270-2HDVSB-IP36-PoE・Hsintek
Applications/Examples of results
Simultaneous monitoring of multiple network camera images (up to 36 cameras can be connected per monitor) and fixed-point observation in multiple areas.
