36-screen split possible IP camera monitor CH-L215-1HDVSB
21.5-inch wide LCD display, a security and monitoring monitor capable of splitting and displaying video from up to 36 IP cameras, high resolution, PoE compatible.
■H.264/H.265 compression format ■Supports IP cameras up to 8MP. ■Graphical and text interface (GUI) ■Control via Ethernet connection ■Supports HDMI/VGA/DVI-D input ■Supports up to 36 network cameras via hub/switch ■ONVIF compliant, supports Real-Time Streaming Protocol (RTP) ■Security-grade metal housing. VESA standard compliant. ■PoE compatible monitor
basic information
Specifications Screen Size: 21.5-inch Wide Display Area: 476.6 x 268.1mm Aspect Ratio: 16:9 Resolution (Max): 1920 x 1080 Display Colors: 16.7M Brightness: 250cd/m² Viewing Angle: 89/89/89/89° Video Input: 1x HDMI / 1x VGA / 1x DVI-D Audio Input (R/L): 2x RCA Headphone Output: 1x 3.5mm Phone Jack Speakers: 2x Built-in Speakers (2W) Split Display Support: 1/2/4/6/8/9/10/16/25/36CH IP Video Support: 8MP/D1 Supported Decoding: H.264/H.265 Supported Protocols: ONVIF, RTSP, i9, SLINK protocol (*RTMP push, DDNS, UPNP, etc.) USB Ports: 2x USB 2.0 PoE Power Source: PoE RJ45 Ethernet Cable PoE Input Range (DC): 36-57V Hub/Switch PoE Requirement: Max 60W Power Consumption: Approximately 24W Dimensions: 532.2 x 323.3 x 56.7mm Weight: 5.4kg Operating Temperature: 0-50℃
Price information
Open price
Delivery Time
Model number/Brand name
CH-L215-1HDVSB-IP36-PoE・Hsintek
Applications/Examples of results
Simultaneous monitoring of multiple network camera images (up to 36 cameras can be connected per monitor) and fixed-point observation in multiple areas.
