Core Ultra Fanless Embedded PC VBOX-3631
Intel Core Ultra Series 3 Processor, embedded PC for railway and automotive applications, certified to railway standard EN50155.
**[SINTRONES VBOX-3650(P)-(M12X) Features]** ■ Dimensions: 160mm wide × 55mm high × 250mm deep, 2.2 liters ■ Equipped with Intel Core i7 / i5 / i3 Series 3 processors ■ Built-in NPU for AI processing ■ Supports DDR5-6400 SO-DIMM up to 64GB ■ Equipped with 2.5GbE×1 + GbE×4 ■ Achieves robust network connectivity with M12 X-code connector compatible model ■ Three video outputs via HDMI, DVI-D, and USB Type-C DP ■ Equipped with 2×CAN FD, RS-232/422/485×2, DIO (DI×6 / DO×4) ■ Supports M.2 NVMe SSD×2, M.2×2 for WWAN, M.2×1 for Wi-Fi/BT ■ Equipped with TPM 2.0 (FIPS 140-3 compliant) ■ Includes watchdog timer and smart power management features ■ Supports a wide power input range of DC 9-60V ■ Compatible with optional BBU (Battery Backup Unit) ■ Fanless aluminum chassis ■ Wide temperature operation range of -40 to 70°C ■ Wall mountable
basic information
Specifications ■CPU: Intel Core i7 350 / Core i5 320 / Core i3 304 ■Memory: DDR5-6400 SO-DIMM x1, maximum 64GB ■Storage: M.2 2280 Key M NVMe SSD x2 ■I/O Connectors: 2.5GbE x1, GbE x4, HDMI x1, DVI-D x1, USB Type-C DP x1, USB 3.2 x2, USB 2.0 x2, RS-232/422/485 x2, CAN FD x2, DI x6, DO x4, isolated DO x1 ■Input Power: DC 9-60V input (3-pin terminal block / M12 K-code) ■Operating Temperature: -40 to 70°C (with airflow, 0.6m/s) ■Certifications: CE, FCC Class A, UKCA, E-Mark, EN 62368-1, EN 50155, EN 45545-2 (R25), CISPR 2 ■OS: Windows 11 IoT Enterprise LTSC, Ubuntu 24.04 LTS or later
Price information
Open price
Price range
P3
Delivery Time
P4
Model number/Brand name
SINTRONES VBOX-3631-(M12X)
Applications/Examples of results
For machine, factory, and building automation/monitoring systems.
