I tried to verify the reproducibility of a mold with a 3D cooling water pipe!
How well can a "3D cooling water pipe" be reproduced with a metal 3D printer? We checked it with a CT scan! | System Create
Mitarepo is a series based on the concept of "Trying out things like this!" that introduces what can be done using various products. The greatest strength of metal 3D printers is their ability to create "complex shapes" that were impossible with traditional machining. For example, designs that incorporate 3D water channels running internally to enhance the cooling efficiency of molds can be realized. However, because such complex shapes can be achieved, it also raises concerns such as: "Are the invisible internal cavities truly connected as designed?" "Is there any powder clogging or distortion of shape?" With that in mind, this time we created a model mimicking an injection molding mold and conducted thorough verification using CT scans to check the "invisible internal state." Are the water channels inside accurately reproduced? The results of this verification, along with a series of processes, are compiled in the materials. Please take a look. *You can download the materials using the button below.
basic information
■What I tried ■First, I created a model using a metal 3D printer ■Completed! How does it look? ■The result of the CT scan is...?
Price range
Delivery Time
Applications/Examples of results
We would be grateful if you could read this as a hint for those considering the advancement of mold manufacturing using metal 3D printers and next-generation cooling designs.
