For Drones | Lightweight Aluminum Die-Cast Parts GAM AL8
Lightweighting drone bodies with low density. Would you like to further reduce the weight of existing aluminum die-cast parts?
Features of GAM AL8 1. High strength & ultra-high ductility & low specific gravity (2.51g/cm³) TS 299–372 MPa YS 165–195 MPa Elongation 11–17% *Test specimen: ASTM E8 Casting method: Die casting 2. High corrosion resistance Complies with PFAS regulations without copper 3. Non-heat-treated, allowing for total cost reduction. 1) Heat treatment costs 2) Labor costs 3) Reduced material costs through weight reduction 4) Shortened production time 5) Does not contain harmful elements or expensive rare metals 4. Environmentally friendly 1) Reduction of CO2 emissions through non-heat treatment 2) Reduced electricity consumption 3) Carbon tax reduction 5. Good fluidity
basic information
Please contact us for the comprehensive catalog and other evaluation materials.
Price range
Delivery Time
Applications/Examples of results
- Four-wheel and two-wheel parts - Mobility parts - Construction materials
catalog（5）
Download All Catalogs
News about this product（5）
-
GOLDRONE ＆ GAM Agreement
A signing ceremony for a letter of intent (LOI) regarding strategic cooperation and investment for the establishment of a joint venture (JV) in the drone and defense industry was held.
-
We conducted a GAM AL8 extrusion test.
In GAM, we are conducting prototypes using AL8 hollow extruded materials in pipe and square tube shapes. The shapes are as follows: - Pipe: Outer diameter 49mm / Inner diameter 40mm - Square tube: 40mm x 40mm / Wall thickness 3.9mm
-
Trial production of die-cast prototypes using AL8.
We conducted a trial for the production of die-cast prototypes using AL8 and performed a basic evaluation including moldability.
-
[GAM CO., LTD.] Global Excellent Enterprises Research Institute Development Project (G-ATC) *Participating in a national project in South Korea.
GAM is participating as a collaborating organization in the "Global Excellent Company Research Institute Development Project (G-ATC)" research and development initiative, which has been selected with Hanju Light Metal Co., Ltd. as the supervising agency, supported by the Ministry of Trade, Industry and Energy of South Korea and the Korea Institute for Industrial Technology Planning and Evaluation (KEIT). This research and development aims to develop aluminum hollow body housings for humanoid robots using semi-solid casting technology with electromagnetic stirring. This project includes Hanju Light Metal Co., Ltd. as the supervising agency, along with GAM, Hyundai Motor Company (demanding organization), Korea Institute of Production Technology, Ulsan Technopark, and Worcester Polytechnic Institute (USA). Through participation in this research and development, GAM will work on the development of high-performance aluminum materials and casting technologies.
-
