High-Quality Thermography for Residential and Leak Diagnosis - Testo 883
We achieve high sensitivity and high image quality required on-site for housing inspections, supporting the improvement of diagnostic accuracy and work quality.
By accurately capturing the gaps in building materials and subtle temperature differences caused by moisture in rain leak diagnostics, we support the improvement of diagnostic accuracy and service quality. ✓ High-resolution thermal images: When using the testo SuperResolution feature: 640 × 480 pixels ✓ High thermal sensitivity to detect slight temperature differences: Temperature resolution 0.04℃ (40 mK) ✓ Clear images achieved with manual focus adjustment: Sharp images even at a minimum distance of 10 cm for close-up shots ✓ For building diagnostics and high-temperature equipment inspections: Easy exchange between wide-angle and telephoto lenses ✓ Surface humidity display mode indicating the risk of mold growth: Mold growth risk displayed in red, yellow, and green signal colors ✓ Visualization of mold growth risk through simultaneous measurement of temperature and humidity: Seamless connection with the separately sold testo 605i temperature and humidity smart probe *For details, please view the PDF data by downloading the catalog. *If you wish to borrow a demo unit for free, please select "Request Demo" from "Contact Us via Web."
basic information
【Specifications (Partial)】 Pixel Count: 320×240 (SR 640×480) Measurement Range: -30 to +650℃ Temperature Resolution: Below 0.04℃ Accuracy (Representative Value): ±(2℃ or measurement value × 2%), whichever is greater Field of View: 30°×23° (Standard) / 12°×9° (Telephoto) / 42°×32° (Wide Angle) / 12°×9° (Telephoto) Focal Length: 10cm~ (Standard) / 50cm~ (Telephoto) / 10cm~ (Wide Angle) / 50cm~ (Telephoto) Visible Camera Digital Zoom: 2x / 3x / 4x Scale Assist ε-Assist IFOV Indicator Wireless Connection: Wi-Fi, Bluetooth (connects with testo 605i/770-3) Memory: Built-in 2.8GB Operating Temperature: -15 to +50℃ Battery: Approximately 5 hours Dimensions: 171×95×236mm
Price range
Delivery Time
Model number/Brand name
0560 8834
Applications/Examples of results
Infrared thermography is mainly used for the following purposes: - Residential and structural diagnostics: leak detection, thermal insulation and heat retention diagnostics, exterior wall peeling diagnostics - Equipment diagnostics: piping heat leak diagnostics, level (filling degree) diagnostics check, electrical equipment diagnostics - Industrial machinery diagnostics: diagnosis of abnormal heat generation in motors, bearings, engines, etc.
