Aluminum foil for positive electrode collector 'KS-81'
Aluminum foil with excellent strength and ductility for the positive electrode current collector of lithium-ion secondary batteries.
We have developed aluminum foil 'KS-81' suitable for improving processing and coating precision, as well as output density, for lithium-ion secondary battery positive electrode current collectors. Thanks to improvements in foil manufacturing technology and foil rolling technology, it has become a very fine metal crystal with high mechanical properties. Additionally, it can be used without compromising processability or basic performance due to the thinning of the aluminum foil. 【Features】 ■ Excellent strength and ductility ■ Ensures conductivity almost equivalent to pure aluminum ■ Offers a wide range of thickness options and can accommodate thinning ■ Cost reduction possible through thinning *For more details, please refer to the catalog or feel free to contact us.
basic information
【Performance (Representative Values)】 *Conductivity is 59 (IACS%) for all thicknesses ○ 10μm Single Gloss Tensile Strength: 255 N/mm Elongation: 1.6% ○ 12μm Single Gloss Tensile Strength: 265 N/mm Elongation: 1.9% ○ 12μm Double Gloss Tensile Strength: 275 N/mm Elongation: 2.5% ○ 15μm Double Gloss Tensile Strength: 275 N/mm Elongation: 3.1% 【Details of Provided Samples】 - Roll samples (for all thicknesses) - Width: Approximately 650 mm - Roll length: Up to 4000 m *For more details, please refer to the catalog, but feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
○ Lithium-ion secondary battery cathode material for automotive use ○ Lithium-ion secondary battery cathode material for consumer use ○ Audio equipment diaphragm *For more details, please refer to the catalog, but feel free to contact us.*
catalog（2）
Download All Catalogs
Recommended products
Distributors
Toyo Aluminum K.K. has been pursuing the potential of aluminum's functionality and design since its founding, developing useful products and contributing to society. By accurately responding to customer needs based on the characteristics of aluminum and research outcomes, we produce foil products tailored to applications in packaging, electronics, and daily necessities, as well as powder and paste products as high-performance materials, and solar cell-related products that consider the global environment. We have grown into a manufacturer that operates globally, not only in Japan but also in Europe, the Americas, China, and other Asian countries. Moving forward, we will leverage our unique core technology as a source of development strength, under the action policy of "Creating the future, I create, we all create," to meet customer demands and contribute to the development of a new society.
