Aluminum casting hole processing spiral tap "ACHSP"
Direct processing of female threads into casting holes is realized! Processing time can be shortened.
The "ACHSP" is a spiral tap designed for aluminum casting holes that allows direct tapping into the casting holes, thereby reducing processing time. It uses a super-fine particle carbide alloy that combines moderate hardness and toughness. By adopting a shank diameter equal to the outer diameter for the blank, rigidity is increased, allowing it to withstand deflection and processing loads caused by misalignment of the casting holes. 【Features】 ■ Eliminates the need for pre-drilling (correction) processing, reducing processing time ■ Utilizes a super-fine particle carbide alloy that combines moderate hardness and toughness ■ Increased rigidity by adopting a shank diameter equal to the outer diameter for the blank ■ Capable of withstanding deflection and processing loads caused by misalignment of the casting holes ■ Coating improves wear resistance and chipping resistance *For more details, please refer to the PDF document or feel free to contact us.
basic information
【Lineup】 ■SY6.0MRLXT(M6×1) ■SY8.0NSLXT(M8×1.25) ■SY010OSLXT(M10×1.5) ■SY010NSLXT(M10×1.25) *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
