Wire tube extrusion drainage air nozzle Part number M472K-W2B
Compressed air is ideal for draining, drying, and cooling electrical wires, tubes, and extruded products.
● Operates solely on compressed air ● Air consumption is reduced to 1/3 to 1/4 compared to conventional nozzle methods ● The interior features non-contact surface blowing with uniform airflow at 360° ● There are no rotating parts inside, and the simple structure ensures no failures ● Line expansion is possible using existing compressors ● Both ends are equipped with ceramic guides that excel in wear resistance ● The main body (manufactured by BSBM) has a chrome-plated finish, providing excellent corrosion resistance (We can accommodate custom requests for SUS, PVC, etc.)
basic information
●Function of this product ●This product converts the compressed air supplied by the compressor into kinetic energy within the main body, and at the same time, the compressed air is ejected at ultra-high speed from the rear through the diffuser, creating a powerful negative pressure at the tip. This allows secondary air from the atmosphere to be drawn in, merging with the primary air, resulting in a unique mechanism that ejects air amplified several times. The amplification ratio is more than 1:6 to 1:10 when the primary air is set to 1.
Price range
Delivery Time
Model number/Brand name
M472K-W2B
Applications/Examples of results
■Purpose ● Air blow drying for water removal in wire drawing pickling processes. Blow drying of tubes and pipes. ● Removal of excess coatings, water, and oil. Drying equipment within cleaning machines. ● Water removal in wire plating lines. Drying during extraction in plastic molding machines. ● Blow drying of sheet metal and metal processing parts, etc.
