Non-contact thermometer for high temperature measurement M1241-Gemini P4.0 MTHHS
It is a portable type that is easy to carry.
Measurement temperature range: 650 to 1800°C Small spot measurement with a diameter of 1mm Measurement wavelength of 1μm, capable of temperature measurement through glass
basic information
■Specifications Model Number: M1241-GeminiP4.0MTH-HS M1241-GeminiP4.0MTH-HC2 Measurement Temperature Range: 650℃ to 1800℃ Temperature Resolution: 0.1℃ (1℃ above 1000℃) Measurement Accuracy: ±(0.5% of reading + 2℃) Reproducibility: ±(0.3% of reading + 1℃) Measurement Field of View: 300:1 At φ12mm @ 3.6m, φ1mm @ 300m Response Time: 100ms Measurement Wavelength: 1μm Aiming: 2-point laser marker (Class 2 / Maximum output 1mW) Emissivity Correction: Variable 0.10 to 1.00 (0.01 step) Functions: Maximum/Minimum/Hold Digital Output: USB Input: Miniature size K thermocouple connector K Thermocouple Specifications: Temperature Range: -40℃ to 400℃ / Measurement Accuracy ±1% or ±1℃ Upper and Lower Limit Alarm: Display + Sound with 3-color LED backlight Main Unit Data Memory: 2000 points Power Supply: 1 x 9V alkaline battery Battery Life: Approximately 12 hours (when laser marker and backlight are on) Accessories: Windows software, USB cable, K thermocouple, tripod mounting hole, carrying case Tripod Mounting Screw: 1/4-20UNC
Price range
Delivery Time
Applications/Examples of results
Note: This product is a high-temperature measuring thermometer intended for industrial use and is not designed for general consumers for everyday use.
