Drawing Attribute Extraction System
Automatic extraction of design information from CAD data.
A system that extracts and aggregates material lists from multiple drawings and outputs them to a summary table. By simply specifying keywords and the direction of acquisition, material lists can be automatically extracted. This significantly reduces the workload for material ordering tasks and enables data system integration. We develop a customer-specific system based on commercially available CAD software, realizing requests that were previously deemed "impossible."
basic information
Data format: DXF/DWG data, SOLIDWORKS data, CADSUPER data
Price range
Delivery Time
Model number/Brand name
Drawing Attribute Extraction System
Applications/Examples of results
Please contact us.
catalog（1）
Download All Catalogs
News about this product（2）
-
We will exhibit at the "Measurement and Measurement Exhibition 2025."
We will be exhibiting at the "Measurement and Inspection Exhibition 2025," which will be held from September 10 (Wednesday) to September 12 (Friday), 2025, at Tokyo Big Sight, West Hall. At the Marble booth, we will primarily showcase our software "Inspection Sheet System," which realizes efficiency in the inspection process, as well as our DX promotion software "Drawing Extractor," which easily extracts design information from drawings. Additionally, we will introduce customized case studies that automate the extraction of drawing information tailored to customer specifications, as well as inspection solutions for promoting DX in quality assurance departments. We will also hold practical application seminars at the venue (Seminar Room F in West Hall 1): September 10 (Wednesday) 11:30 AM - 12:00 PM: "Zero Handwriting! Creating Inspection Reports in Two Steps" September 11 (Thursday) 1:00 PM - 1:30 PM: "Shall We Start with Inspection Operations? Quality Assurance DX" We look forward to your visit.
-
Explaining tips and precautions for improving the efficiency of blueprint extraction work! Case study on dedicated system development released.
The task involves extracting design information from drawings and transcribing it into specifications, purchase orders, project proposals, cost estimates, proposals, sales materials, and so on. The process of extracting information from those drawings primarily consists of searching for the necessary information (text strings) for cost estimation and transcribing it into Excel. We would like to introduce a case of a dedicated system developed for automation aimed at further improving work efficiency.
