Printer mechanism 'FTP-66EMCL112'
Compact design compatible with 6 inches (maximum paper width 156mm)! Safety standards have been obtained.
The "FTP-66EMCL112" is a thermal printer mechanism that can operate on both 12V and 24V power supplies. Despite being compatible with 6-inch media, it features a compact design and a platen open structure that makes maintenance, such as paper setup and paper jam clearance, easy. Additionally, when operating at 24V, it offers high-speed printing of up to 100mm/second, and the paper path is a straight path, making it suitable for label paper as well. 【Features】 ■ Compact 6-inch printer mechanism ■ Easy maintenance with a platen open structure ■ High-speed printing ■ Compatible with label paper *For more details, please refer to the PDF document or feel free to contact us.
basic information
【Specifications (Excerpt)】 ■Printing Method: Thermal Line Dot Method ■Dot Configuration: 1152 dots/line ■Effective Printing Width: 144mm ■Printing Speed: Up to 50mm/second (at 12V operation), up to 100mm/second (at 24V operation) *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Usage】 ■Medical devices, measurement instruments, financial terminals, KIOSK, etc. *For more details, please refer to the PDF document or feel free to contact us.
