Standard heat sink "20PB017"
Height 20.00mm, width 16.50mm! The extrusion profile tolerance is JIS H4100 ordinary grade.
We would like to introduce our standard heat sink, '20PB017'. The material is aluminum alloy, specifically A6063S-T5, with the pin part made of brass with tin plating. The height is 20.00mm, width is 16.50mm, and the weight is 0.353kg/m. Additionally, the extrusion tolerance is JIS H4100 ordinary grade, with cutting dimension tolerance of ±0.5 within 300mm, and machining tolerance is JIS B-0405 intermediate grade. 【Specifications (partial)】 ■ Material: Aluminum alloy ■ Material: A6063S-T5; Pin part: Brass with tin plating ■ Extrusion tolerance: JIS H4100 ordinary grade ■ Cutting dimension tolerance: ±0.5 within 300mm ■ Machining tolerance: JIS B-0405 intermediate grade *For more details, please download the PDF or feel free to contact us.
basic information
【Other Specifications】 ■Height: 20.00mm ■Width: 16.50mm ■Weight: 0.353kg/m *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
