Poka-Yoke Wireless Unit HCP-2403T-MD
It is possible to create poka-yoke devices that can be globally compatible without wireless circuit design!
The HCP-2403T-MD is a wireless unit that can communicate with the TW-800 series error-proofing receivers. It comes standard with a pairing switch, LED monitor, antenna, and communication interface for external devices, allowing for the construction of error-proofing equipment without the need for wireless circuit design by integrating it into power tools, jigs, and equipment. Since there is no need for development related to wireless technology, it significantly reduces development man-hours while achieving stable wireless communication. Additionally, due to its unique communication protocol, there are no licensing fees or annual costs, making it suitable for small-scale starts. Furthermore, it allows for the wireless transmission of arbitrary data through simple command sending via UART, enabling the transmission of information from power tools, jigs, and equipment to higher-level PLCs or PCs. The HCP-2403T-MD can be retrofitted into Makita Corporation's screwdrivers. 【Available Countries】 Japan / Canada / United States / China / Thailand / India
basic information
【Specifications (Excerpt)】 ■ Operating Frequency: 2,403MHz to 2,478MHz ■ Display: 2 LED indicators (for communication monitoring and battery level notification (green/red)) ■ Input: 1 pairing switch ■ Interface: 1 connection connector (5-pin/1mm pitch) ■ Power Supply: DC 1.8V to 5.5V ■ Dimensions: 20.0W × 30.0H × 6.25D mm ■ Communication Range: Approximately 30m indoors (varies by environment) ■ Usable Countries: Japan / Canada / United States / China / Thailand / India *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
The HCP-2403T-MD can be retrofitted and built into screwdrivers manufactured by Makita Corporation. 【Makita screwdrivers compatible with HCP-2403T-MD】 *Japan Screwdrivers FT060TDNZH/FT120TDNZH
