[Processing Examples] Precision Equipment / Food Machinery / Medical Device Industry
We will introduce examples of achieving improved device accuracy, reduced vibration, and easier assembly!
We would like to introduce a case study of the production of shouldered long holes processed inside precision shafts for the food, medical, and analytical equipment sectors. In this case, there were challenges related to the unique issues of galling and maintaining precision with stainless steel. However, through our company's efforts, we were able to achieve improvements in equipment precision, reduction of vibrations, and ease of assembly. Our company has many years of experience and advanced technology in the fields of deep hole processing and gun drilling. Utilizing advanced gun drilling technology that enables precise deep hole processing, we provide high-quality machining services tailored to our customers' requirements. 【Case Overview】 ■ Industry: Precision Equipment / Food Machinery / Medical Devices ■ Part Information: SUS303, φ12.7×208.7mm shouldered, concentricity 0.02mm ■ Challenge: Difficulty in maintaining precision and galling unique to stainless steel ■ Provided Value: Maintained high precision with concentricity of 0.02mm and anti-galling processing ■ Technical Points: Optimization of cutting conditions for stainless steel, heat dissipation control, and shoulder finishing processes *For more details, please download the PDF or feel free to contact us.
basic information
【Other Case Summary】 ■Quality Control: Three-dimensional measuring machine, pin gauge, coaxiality measurement ■Lot/Delivery: 3 units, capable of prototype and mass production, additional processing available ■Final Results: Improved equipment accuracy, reduced vibration, easier assembly *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
catalog（1）
Download All Catalogs
Recommended products
Distributors
Haitak boasts industry-leading contract gun drilling processing technology, catering to a wide range of industries including medical, aerospace, automotive, and semiconductors. Our in-house developed gun drilling machines are equipped with high rotational precision and built-in servo spindles, enabling deep hole processing exceeding L/D200. By manufacturing over 1,000 types of gun drills and special jigs in-house, we meet all customer needs. From small diameter to large-scale operations, we contribute to solving customer problems with precision and speed. Our machines, equipped with unique technology and international patents, excel in reliability and cost performance, making them the optimal choice for engineers. Haitak resolves all challenges in deep hole processing and provides complete satisfaction to our customers.
