Cu seed layer etching solution

For the Cu plating/Cu seed structure, it etches the Cu seed layer with minimal damage to the Cu plating wiring and bumps.

The features of this product are as follows: - There is less thinning of the Cu plating. - There is less surface roughness of the Cu. - It can be applied to various seed layers (from electroless copper plating to sputtered copper). - It supports various methods such as dip, spray, and spin. Keywords: wet etching, copper, plating, seed layer, selective semi-additive method.

basic information



Price range

Delivery Time

Applications/Examples of results

Please contact us.

Cu seed layer etching solution "Pure Etch C203・C210"
