ALICAT Mass Flow Controller MCQ Series (High Pressure Type)
The maximum operating pressure is 320 PSIA (2.2 MPaA). The pressure resistance is 400 PSIA (2.7 MPaA). It is also compatible with mixed gases!
The "MC/MCP/MCR series" is a high-pressure mass flow controller manufactured by ALICAT that can handle 98 different types of diverse gases with a single unit. It achieves a fast response through a laminar flow method (differential pressure type). Equipped with a highly accurate differential pressure sensor, it measures flow rates precisely. In addition, we offer a lineup such as the "MCHQS/MCRQS series," which supports 128 types of gases, including corrosive gases and refrigerant gases. 【Features】 ■ 100ms control response ■ High flow accuracy of ±(0.8% RD + 0.2% FS) ■ Lineup from 0.5 SCCM to 5000 SLPM ■ Standard analog output and RS 232C communication ■ Compatible with mixed gases ■ Standard equipped with a backlit LCD display *For more details, please refer to the PDF document or feel free to contact us.
basic information
【Lineup】 ■ MC/MCP/MCR Series (Standard Type) ■ MCS/MCRS Series (For Corrosive Gases/Refrigerant Gases) ■ MCW/MCRW Series (Low Pressure Loss Type) ■ MCQ/MCRQ Series (High Pressure Type) ■ MCV/MCVS Series (Equipped with Shut-off Valve) ■ MCD/MCRD Series (Dual Valve) *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
