SIRC Cloud Package
The first step in energy conservation starts here. [SIRC Cloud Package]
■■What You Can Do with SIRC Cloud■■ ~Easily Visualize On-Site Data~ The management screen is easily accessible from a browser. You can share on-site data with group companies and business partners. ~Provide Energy-Saving Tips with Analysis Functions~ Check the correlation between on-site data and power consumption. Identify large power-consuming equipment and unexpected waste. ~Notify Equipment Abnormalities via Email~ By setting thresholds in advance, you can detect abnormalities and receive email notifications. This allows for early detection of issues and prevention of troubles. ■■What is the SIRC Cloud Package?■■ This is a flat-rate plan that can be implemented with four sensors tailored to the environment of factories or facilities, along with SIRC Cloud. It is recommended for companies that want to advance their understanding of CO2 emissions across the entire supply chain with Scope 3 compliance, as well as for small-scale implementations by companies that have not yet started energy-saving initiatives.
basic information
■■■ SIRC Cloud Package Contents ■■■ 【Cloud Service】 - SIRC Cloud 1 account, 1 year usage fee 【Gateway, Gateway】 - Cloud Gateway / DGW01-020 - Data Logger / DLG03-060 * One of either device will be loaned. * The functions available differ between the Cloud Gateway and the Data Logger. 【Loaned IoT Sensors】 Four units will be loaned from the models listed under "Loaned IoT Sensors" below. * Model changes for loaned items during the contract period are not allowed. ---- Power Sensor Unit ---- - Battery Models: DDS33-0903P / DDS13-0903P DDS33-1510P / DDS13-1510P DDS33-2520P DDS33-3530P - High-Speed Models: DDS33-0903R / DDS33-1510R DDS33-2520R / DDS33-3530R ---- IoT Digital Input Unit ---- - DCU03-001EN
Price range
Delivery Time
Model number/Brand name
SIRC Cloud Package【DCLP1-012】
Applications/Examples of results
■Easy visualization of on-site data ■Provides energy-saving tips through analysis functions ■Notifies equipment abnormalities via email
Detailed information
-
【Scope3 Energy Saving Improvement Function】 Equipped with a "correlation analysis function" that shows the relationship between production quantity and electricity consumption, and an "energy loss analysis function" that identifies energy losses and highlights improvement points. By clarifying the improvement points, it can lead to effective energy-saving plans.
-
【Dashboard】 You can check the overall picture for the current month. By reviewing the total amount and breakdown, you can understand the trends for the month. *This is a feature exclusive to Cloud Gateway.*
-
【Data Details】 You can check the data for the specified period. By aggregating multiple sensors or displaying them individually, you can obtain detailed information. It is also possible to compare with past data, such as month-on-month or week-on-week comparisons. *This is a feature exclusive to the cloud gateway.*
-
【Data Download】 You can download data for the specified period as CSV data. The CSV data includes electric power, cumulative electric power, active power, apparent power, power factor, current value, sensor battery voltage, and more.
-
【Power Analysis】 You can easily compare any two pieces of data. Set the periods before and after, and compare the average active power during that time. From the operating hours, the reduction effect on an annual basis is clarified. *This is a feature exclusive to the Cloud Gateway.*
Distributors
SIRC Corporation provides IoT sensors that can be retrofitted to existing equipment without large-scale construction for factories and plants. The main products include the "IoT Power Sensor Unit," which allows for easy measurement of power consumption for each piece of equipment and can be installed in about 15 seconds, and the "IoT Angle Sensor Unit," which can convert existing analog meters into IoT devices. Additionally, SIRC has developed its own cloud service, "SIRC Cloud," to visualize this data and support centralized management of on-site data. SIRC supports "on-site DX" that can be initiated while valuing and making the most of existing equipment.
